Char-Broil 7301411 Product Manual

Char-Broil 7301411 Product Manual

Santa fe
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product Guide
Model 07301411
Santa Fe
Tools needed for assembly:
Phillips Screwdriver
Flat Head Screwdriver
Two adjustable wrenches
Hammer
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off
carbon monoxide, which has no odor. NEVER burn
charcoal inside homes, vehicles, or tents.
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Char-Broil®; America's Legendary Barbeque Company®; American Gourmet®; Bandera®; BrushHawg®; CB940®;
Char-Diamonds®; Char-Broil Charcoal/Gas®; DiamondFlame®; Everybody Grills®; Everybody Outside®; FastStart®; Fireball®; Firenzy®; FlavorMaster®; Grill2Go®; Grill2Go® Express®; Grill Lovers®; H20 Smoker®;
Keepers of the Flame®; New Braunfels Smoker Company®; Oklahoma Joe's®; Patio Bistro®; Patio Caddie®; Patio Kitchen®; Precision Flame®; Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature Series®; The
Big Easy®; The Minute Grill®; Trentino®; Wild West Tradition®; and the following marks:
The following are trademarks of W.C. Bradley Co.: Commercial Series™; Designer Series™; Grill2Go® Advantage™; Longhorn™; Double Chef™; QuickSet™; Ready When You Are™; Hog and Yard Bird™; You Bring the
Party™; SureFire™; Universal Grill Parts™ TEC™ is a trademark of Tec Infrared Grills.
Protected under one or more of the following U.S. Patents: 4,989,579; 5,421,319; 5,458,309; 5,579,755; 5,996,573; 6,114,666; 6,135,104; 6,209,533; 6,279,566; 6,331,108; 6,484,900; 6,526,876; 6,595,197; 6,640,799; 6,640,803; 6,729,873; 6,739,473; 6,749,424;
6,863,100; 6,935,327; 6,951,213; 6792,935; 7,047,590; D364,535; D372,637; D373,701; D377,735; D383,035; D397,910; D405,643; D406,005; D406,009 ; D413,043; D413,229; D414,982; D415,388; D416,164; D416,441; D417,587; D417,588; D422,516; D423,876;
D428,303; D430,772; D435,396; D436,004; D438,059; D438,060; D438,427; D439,110; D442,505; D443,179; D443,354; D443,464; D447,384; D447,385; D447,909; D448,610; D448,614; D448,615; D448,616; D448,975; D449,492; D450,544; D451,759; D454,028;
D454,031; D455,205; D455,206; D456,202; D456,222; D456,223; D457,789; D458,520; D458,760; D458,802; D459,088; D459,148 D459,149; D459,161; D459,163; D459,586; D459,943; D460,312; D460,313; D460,318; D461,359; D465,123; D465,693; D466,307;
D466,439; D466,752; D473,414; D474,371; D477,498; D477,501; D477,504; D477,506; D477,746; D478,471; D478,472; D480,914; D491,410; D494,009; D494,413; D498,523; D500,359; D504,048; D530,098; D535,000; Canada: 87,743; 87,744; 97,504; 99,355;
102,037; 104,200; 2,315,567; 2,336,036; France: 010,231; 010,422; 010,590; 010,849; 1,089,646; Germany: 1,089,646; South Korea: 384,565; China: 99,127,066.5; United Kingdom: 2,099,402; 1,089,646. Other Patents Pending. © 2008 W.C. Bradley Company
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
TM REVISION 00
FOR OUTDOOR USE ONLY
Estimated Assembly Time: 1 Hour
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION:
THIS UNIT IS HEAVY! DO NOT attempt to
assemble without a helper.
®
®
1-800-241-7548
.
42804335 - 07/07/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7301411 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Char-Broil 7301411

Summary of Contents for Char-Broil 7301411

  • Page 1: Product Record Information

    102,037; 104,200; 2,315,567; 2,336,036; France: 010,231; 010,422; 010,590; 010,849; 1,089,646; Germany: 1,089,646; South Korea: 384,565; China: 99,127,066.5; United Kingdom: 2,099,402; 1,089,646. Other Patents Pending. © 2008 W.C. Bradley Company If you have questions or need assistance during assembly, please call 1-800-241-7548 To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register 42804335 - 07/07/08 TM REVISION 00...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING Product Record Information ......1 FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR For Your Safety .

  • Page 3: Preparing To Use Your Grill

    PREPARING TO USE YOUR SANTA FE GRILL Before cooking with your Santa Fe Grill, the following steps should be closely followed to both cure the finish and season the interior steel. Failure to properly follow these steps may damage the finish and/or impart metallic flavors to your first foods.

  • Page 4: Cooking Tips

    COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate or ash pan. We recommend using 4 pounds (approximately 50 - 60 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes.
  • Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.

  • Page 6: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 7: Parts List/ Parts Diagram

    PARTS LIST Key Qty Description Part # Key Qty Description Part # Firebox Assembly....29101712 Wood Rack..... . 29101733 Rear Panel .

  • Page 8: Assembly

    ASSEMBLY • Open carton and place contents onto a clean floor. • Place bottom on ground with clean out door opening facing ground. • Attach rear panel to the bottom with (4) 1/4-20x1/2” hex screws. • With lower section still in position from previous step, attach (1) short leg to the right end and (1) Outside and flange nuts on inside.
  • Page 9 This may require at least two people • Hook the back side of wood rack into two attached legs as shown (A). • Attach (1) short leg and (1) long leg to front of bottom assembly by first hooking legs onto wood rack, then position legs so that they are aligned with holes in bottom.
  • Page 10 • Attach clean out door using (4) 1/4-20x1/2” hex screws from outside. Make sure body side of each hinge is attached UNDER bottom. • Attach wood handle to top assembly using (2) 1/4-20x3” screws through handle, sliding an aluminum spacer onto each screw, placing screws through front holes and attaching with (2) 1/4-20 flange nuts.
  • Page 11 • Place top assembly on top of bottom assembly. Align hinge hole on back of unit. With aid of a helper attach hinges to top Assembly using (4) 1/4-20x1/2” hex screws. • Slide hook end of (1) wire door stop into slot in end panel •...
  • Page 12 • Attach (2) daisy wheel dampers to bottom assembly and (2) daisy wheel Dampers to top assembly using (1)1/4-20x1/2” hex screw, (2) flat washers and (1) reversible lock nuts as shown. DO NOT FULLY TIGHTEN to Allow for damper adjustment. Lid removed for clarity •...
  • Page 13 • Lower ash pan into bottom section. Set hooks into holes in each • Attach a wire ash pan hanger to each end of the ash pan. Once end of the lower body. Raise and lower ash pan as desired for attached hanger hooks should be facing away from ash pan.

  • Page 14: Hardware List

    Insert the swing away grate rod into the hole on the left side of the lid, then insert the rod into the hole on the right side of the lid. Shown A Carefully insert the swing away grate support rods into the holes in the fire box. Shown B.

  • Page 16: Registration Card

    Please register your product online at: www.charbroil.com/register (If you register online, you do not need to send in this registration card.) PLEASE FILL OUT THIS CARD AND RETURN IT WITHIN 10 DAYS OF PURCHASE. FAILURE TO RETURN MAY AFFECT YOUR WARRANTY COVERAGE. FOR WARRANTY SERVICE PROOF OF PURCHASE WILL BE REQUIRED.
