PRODUCT GUIDE
MODEL 463231711
See rating label on grill for serial number.
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-888-430-7870.
Estimated assembly time: 30 minutes
®
Assembly instructions © 2010
11/16/10 • G520-001-130801

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 463231711 and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Broil 463231711

Summary of Contents for Char-Broil 463231711

  • Page 1 The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling That’s All About U®;...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS For Your Safety ........2-3 Use and Care .
  • Page 3 WARNING CALIFORNIA PROPOSITION 65 1. Combustion by-products produced when using this product contain chemicals known to the State of California to cause cancer, birth defects, and other reproductive harm. 2. This product contains chemicals, including lead and lead compounds, known to the State of California to cause cancer, birth defects or other reproductive harm.

  • Page 4: Use And Care

    USE AND CARE DANGER • NEVER store a spare LP cylinder under or near the appliance or in an enclosed area. • Never fill a cylinder beyond 80% full. • An over filled or improperly stored cylinder is a hazard due to possible gas release from the safety relief valve.

  • Page 5: Connecting Regulator To Lp Cylinder

    LP Cylinder Exchange •Many retailers that sell grills offer you the option of replacing your empty LP cylinder through an exchange service. Use only those reputable exchange companies that inspect, precision fill, test and certify their cylinders. Exchange your cylinder only for an OPD safety feature-equipped cylinder as described in the "LP Cylinder"...
  • Page 6 Hold coupling nut and regulator as shown for proper connection to LP cylinder valve. 6.Turn the coupling nut clockwise and tighten to a full stop. The regulator will seal on the back-check feature in the LP cylinder valve, resulting in some resistance. An additional one-half to three-quarters turn is required to complete the connection.
  • Page 7 WARNING For Safe Use of Your Grill and to Avoid Serious Injury: • Do not let children operate or play near grill. • Keep grill area clear and free from materials that burn. • Do not block holes in sides or back of grill. •...

  • Page 8: Match-Lighting

    Ignitor Lighting (continued) 8. For grills equipped with ELECTRONIC IGNITION at each burner: Repeat steps 4 through 6 to light each burner. 9. Once each burner has ignited, turn knobs to desired setting. WARNING Turn controls and gas source or tank OFF when not in use.

  • Page 9: Spider Alert

    CAUTION SPIDER ALERT! SPIDER AND WEBS INSIDE BURNER TUBE If you notice that your grill is getting hard to light or that the flame isn’t as strong as it should be, take the time to check and clean the venturi’s. VALVE CONTROL PANEL In some areas of the country, spiders or small insects have been...

  • Page 10: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 11: Parts List

    PARTS LIST Description BOTTOM SHELF TANK SCREW, F/ BOTTOM SHELF CASTER, LOCKING CASTER, FIXED CART LEFT SIDE PANEL GROMMET, F/ REGULATOR HOLE CART RIGHT SIDE PANEL CART LOWER BACK PANEL FRONT BRACE HEAT SHIELD, F/ TANK LEFT RAIL, F/ GREASE TRAY RIGHT RAIL, F/ GREASE TRAY FIREBOX MATCH HOLDER...

  • Page 12: Parts Diagram

    PARTS DIAGRAM...

  • Page 13: Assembly

    ASSEMBLY Place bottom shelf upside down. Insert Bent U Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the bottom shelf until secure. Remove the Bent U Pin and repeat for remaining casters.
  • Page 14 Place lower back panel between side panels at rear of bottom shelf. Make sure the slots are positioned as shown (A). Secure lower back panel to side panels using four 1/4-20x1/2” screws, 7mm lock washers, and 7mm flat washers on each side. 7mm flat washer This step requires two people to lift and position grill head...
  • Page 15 On back of grill, place upper back panel between side panels and above lower back panel. Secure upper back panel, in lower holes, using one 1/4-20x1½” screw, 7mm lock washer and 7mm flat washer on each side. Do not fully tighten screws until side shelf installation is complete in later steps. Upper back panel 1/4-20x1½”...
  • Page 16 Remove the two 1/4-20x3/4” screws, 7mm lock washers and 7mm flat washers factory attached to the towel bar. Hang the four S hooks on towel bar. Attach towel bar to right side shelf using screws and washers that are removed from towel bar, shown Insert flange on right side shelf into side shelf brackets on side of firebox, shown B.
  • Page 17 Insert tabs on left sideburner shelf assembly into rectangular slots in side of firebox, shown A. Attach rear of shelf using one 1/4-20x3/4” screw, 7mm flat washer,7mm lock washer and 1/4”nut in upper hole; and using 1/4-20x1½” screw, 7mm lock washer, 7mm flat washer in lower hole, shown B/C. Attach front of shelf and fascia using two 1/4-20x3/4”...
  • Page 18 Insert front brace under control panel and between cart side panels. Make sure door hinge pins are on the top side and facing the front. Secure using two 1/4-20x1½” screws, 7mm lock washers, and 7mm flat washers on each side. NOTE: MAKE SURE THAT THE FRONT BRACE IS MOUNTED IN THE MOST DOWNWARD POSITION WHEN ASSEMBLED TO CART.
  • Page 19 Insert sideburner burner into left shelf. shelf, shown A. Secure burner to sideburner drip pan with one Wing nut, shown B. sideburner ignitor wire to electrode. engages sideburner valve, shown C. Wing nut electrode ignitor wire Place sideburner lid onto left shelf and align holes in back of lid with hinge holes. Secure lid to hinges using four #10-24x3/8” screws, 5mm flat washers, 5mm lock washers, and #10-24 hex nuts.
  • Page 20 Place sideburner grate and griddle into sidebruner shelf. Inside of cart, insert rear heat shield tabs(without holes) into three slots between upper and lower back panels, shown A. Attach shield tabs under front brace with three #8x3/8” self-tapping screws. slots beneath grease tray opening in rear upper panel. Some components not shown for illustration purposes.
  • Page 21 Inside of cart, insert end of tank wire (without hole) into back of lower back panel. Attach other end to bottom of front brace with a #8x3/8” self-tapping screw. Front brace #8x3/8” self-tapping screw Tank wire end of tank wire Inside of cart, insert tank exclusion wire ends into lower back panel.
  • Page 22 Release the cap and nut from electronic ignition module. Attach electronic ignition module to the cart right side panel with the nut, shown A. Insert AA battery into ignition module, negative ( Connect each of the wires from the main burner electrodes, and sideburner electrode into the back of the electronic ignition module.
  • Page 23 Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in back of firebox. Flame tamer Slide into slots...
  • Page 24 Place cooking grates onto the firebox as shown. Insert the two wire ends at rear of warming rack into holes in back of firebox. Front wires of warming rack rest on sides of firebox. On back of grill, slide grease tray into opening in upper back panel. Cooking grate Failure to install grease tray will cause hot grease to drip from bottom...
  • Page 25 LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use & Care section). Once cylinder has been filled and leak checked, place cylinder into hole in bottom shelf. Make sure cylinder valve is facing front of grill.

  • Page 26: Troubleshooting

    EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Gas leaking from • Damaged hose. cracked/cut/burned hose. Gas leaking from LP • Mechanical failure due to rusting or cylinder.
  • Page 27 Troubleshooting (continued) Problem Possible Cause Burner(s) will not light ELECTRONIC IGNITION: using ignitor. • No spark, no ignition noise. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • Sparks, but not at electrode or at full strength. Burner(s) will not •...

  • Page 28: Troubleshooting - Electronic Ignition

    Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause SECTION I No sparks appear at • Battery not installed any electrodes when properly. Electronic Ignition Button is pressed; no noise can • Dead battery. be heard from spark module. • Button assembly not installed properly.
  • Page 29 NOTES...
  • Page 30 NOTES...

  • Page 31: Registration Card

    Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240...
