Summary of Contents for CalAmp SMC-CDMA Series
- Page 1 L a n d C e l l S M C E m b e d d e d W i r e l e s s M o d e m C D M A 1 X R T T U n i v e r s a l S o c k e t User Manual 001-0004-819 Rev01;...
- Page 2 REVISION HISTORY Rev00 Released 01/2010 Minor corrections Rev01 Added Appendix for DUN 11/2011 connection...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION 1 - PREFACE ................... 5 Copyright Notice ....................5 Modem Design Considerations ................5 Modem Use ......................6 Interference Issues ....................6 Mobile Application Safety ..................6 Related Documents ....................6 SECTION 2 - ABBREVIATIONS ................7 SECTION 3 - PRODUCT OVERVIEW ................ - Page 4 TABLE OF CONTENTS SECTION 10 - AT COMMAND REFERENCE .............. 35 AT Command Types .................... 35 Command Line Syntax ..................35 Result Codes ...................... 36 Modem ID Commands ..................36 Hardware Information Commands ................ 37 Modem Configuration, Profile, & Interface Commands ..........37 PRL and PRI Commands ..................
-
Page 5: Preface
Copyright Notice ©2010 CalAmp. All Rights Reserved. This manual covers the operation of the CalAmp SMC-CDMA Embedded Wireless Modem. Specifications described are typical only and are subject to normal manufacturing and service tolerances. CalAmp reserves the right to modify the equipment, its specification or this manual without prior notice, in the interest of improving performance, reliability or servicing. -
Page 6: Modem Use
Modem Use The SMC-CDMA modem is designed and intended for use in fixed and mobile applications. ―Fixed‖ assumes the device is physically secured at one location and not easily moved to another location. Please keep the cellular antenna of the SMC-CDMA at a safe distance from your head and body while the modem is in use (see below). -
Page 7: Abbreviations
Abbreviation Description Access Point Name CDMA Code Division Multiple Access Circuit Switched Data Clear to Send Data Carrier Detect Data Communication Equipment Data Terminal Equipment Dial-Up Network EDGE Enhanced Data rates for Global Evolution GPRS General Packet Radio Service Global Positioning System Global System for Mobile communication IMEI International Mobile Electronic Identity... -
Page 8: Product Overview
MEID: The Mobile Equipment Identifier of the cellular module (hexadecimal format). General Description The LandCell SMC-CDMA embedded wireless modem from CalAmp is a versatile, cost- effective wireless communications device designed for the industry-standard universal socket. Dual-band 800/1900 1x CDMA offers compatibility with many cellular networks. -
Page 9: Smc-Cdma Module Description
SMC-CDMA Module Description Top side reference Fig. 2.1 SMC-CDMA Top Side SMC-CDMA top side components: 1. Power: Green LED indicating cell module power on. 2. CDMA: Red LED indicating CDMA connection status. 3. RF (antenna): MMCX socket, primary antenna connection. 4. -
Page 10: Bottom Side Reference
Bottom side reference Fig. 2.2 SMC-CDMA Bottom Side SMC-CDMA bottom side socket pins: 1. VCC/GND pins 2. –RESET/GND pins Antenna 3. Primary Serial UART pins -RTS2 -CTS2 Secondary -RXD2 UART 2 -TXD2 -RESET -DTR -DCD -CTS Primary -DSR UART 1 -TXD -RXD -RTS... -
Page 11: Pin Descriptions
Pin Descriptions Pin # Description Name Type This signal can be used to turn the C24 module on or off. If the unit is on, asserting a low for a minimum of 2 seconds will shut the C24 module off. Asserting a low for not more than 0.5 seconds will -RESET Input power the C24 back on. -
Page 12: Development/Test Board Interface
Development/Test board The Development/Test board can be used to interface the SCM-CDMA modem to a standard RS232 serial connection. The SMC test board also supplies the SMC-CDMA modem with the required +5VDC supply voltage from an externally supplied 10 to 28 VDC power source, +12VDC typical. Figure 4.1 SMC modem with DK test board 001-0004-819 Rev01 Page 12 of 62... -
Page 13: Accessories
SMC-CDMA test board components: 1. SMC-CDMA modem 2. MMCX to SMA RF cable: Provides connection to external antenna. 3. RS-232 Port: Standard D-Sub, 9 pin, female connector. 4. Power Connector: Molex 4-pos 3MM receptacle (lower left: GND, lower right: +VDC). 5. -
Page 14: Getting Started Using The Smc Test Board
This section describes the use of the SMC test board to communicate with the SMC modem for provisioning and testing using HyperTerminal. Please refer to Appendix A for details on setting up a modem driver for a DUN connection. Connecting Up the SMC Test Board Connect the Power cable, RS232 cable, Antenna cable to the SMC test board as shown in Figure 5.1. -
Page 15: Verify Smc Modem Connectivity
Verify SMC Modem Connectivity Power on the SMC test board (+12VDC typical), then start HyperTerminal. Figure 5.2 HyperTerminal screen responses The ATI command prints the cell module product information. If you get an Error or no communication, verify the modem is connected to the proper COM port and powered on. Refer to Figure 5.2 for all the AT commands listed below. -
Page 16: Smc-Cdma Provisioning
OMA-DM SPRINT Sprint provides customer functionality and miscellaneous services that will utilize "server-initiated" OMA DM sessions. These services include, but are not limited to, firmware updates, PRL updates, and application downloads, etc. The OMA-DM sessions can be initiated by the network (NI) or by the Client (CI). Sprint requires that OMA-DM runs in profile 0, and other data sessions run in profile 1. -
Page 17: Verify Activation Using Hyperterminal
Verify Activation using HyperTerminal With the provisioned SMC-CDMA modem installed, power on the SMC test board (+12VDC typical) and start HyperTerminal as described in Section 5. Type the AT+MIPCALL=1 command to start a PPP connection with the carrier network. If the module is provisioned properly, an IP address will be assigned. Type AT+MPING=1,”www.google.com”. -
Page 18: Verify Activation Using A Dial-Up-Network Connection
Verify Activation using a Dial-Up-Network Connection A Windows Dial-up network connection can be used to verify carrier activation on the network. Create a dial-up network connection using a standard modem set to 115200 bps. Go to the Network Connections screen and double click on the Dial-Up connection (example: SMC-CDMA). When the connect window appears, set the username and password as defined for your carrier (usually blank). - Page 19 The modem will attempt to connect to the provider network. If the configured baud rate for the COM port, the modem, and the DUN do not match, the DUN will not be able to talk to the modem properly and you will get a hardware error message. Otherwise the DUN will contact the cellular network and authenticate the user on the network.
- Page 20 Right click on the connected Dial-Up connection icon and select the Details tab. The status of the connection will be displayed, including the IP address assigned by the carrier network. 001-0004-819 Rev01 Page 20 of 62...
-
Page 21: Smc-Cdma Operational Features
This section provides information on various features and call scienerios using the SMC-CDMA modem with the SMC Development/Test board and HyperTerminal. The SMC-CDMA modem integrates Telit’s MOT-C24 cell module and uses it’s serial UART interface. See related document, MOT by Telit C24 Developer’s Guide, AT Commands Reference Manual [1] for more detailed descriptions and examples for all features and call types. -
Page 22: Circuit Switched Data (Csd)
Circuit Switched Data (CSD) Data transfer over Circuit Switched Data (CSD) is possible. Once the connection is established, data can be transferred to and from the remote side. CSD operation enables the terminal to perform a data transfer over a circuit switched link. It enables the user to: Connect to a remote modem without any Internet network involvement. -
Page 23: Short Message Service (Sms)
Short Message Service (SMS) The SMS feature provides means for SMS messages handling and the reporting of SMS reception events. The SMC modem SMS implementation is based on the 3GPP 23.040 specification. The SMS, as defined within the GSM 800/1900 digital mobile phone standard: A single short message can be up to 160 characters of ASCII text in length (7-bit coded). -
Page 24: Fax
The SMC modem supports FAX Service Class 2.0. A Service Class 2.0 facsimile provides a level of services necessary to support Group 3 facsimile operation. This requires support from the facsimile terminal to implement the recommended T.30/T.32 procedures for document facsimile transmission and recommended T.4 for representing facsimile images. -
Page 25: Internet Services
Internet Services The modem has an embedded TCP/IP stack that is driven by AT commands and enables the host application to easily access the Internet. The advantage of this solution is that it eliminates the need for the application manufacturer to implement their own TCP/IP and PPP stacks, thus minimizing cost and time to integrate Internet connectivity into a new or existing host application. -
Page 26: Udp/Ip
3. After connecting to the CDMA 1x network, the "server" sends its IP address to the SMC modem using an alternative connection (for example, CSD, SMS and so on). 4. The server application listens on a known port, waiting for SMC modem to connect. 5. -
Page 27: Online Data Mode
5. Sending (accumulating) data is done using the +MIPSEND command. 6. Actual send is done using the +MIPPUSH command, by specifying the IP address and port number of the destination. NOTE: Every +MIPPUSH sets the destination IP address and destination port number for the current and future transactions. - Page 28 Each socket, opened in Online Data Mode, allocates an accumulating buffer whose size is 1372 bytes. When the user sends amount of data, less then the buffer size, the data is being sent to Network after a spooling timeout (200 mS), otherwise the data is being sent to Network immediately.
-
Page 29: Ftp Connection
FTP Connection SMC modem implements FTP connection feature, based on RFC959 standard, and operates as a FTP client. When connected to a remote FTP server, SMC modem is able to receive information about remote file system, manage it and perform files transfer operations. The AT+FTPOPEN command is used to open a FTP connection with a remote FTP server. - Page 30 The file transfer operation allows the user to transfer a file over an established FTP connection. To avoid end-of-file detection problem for user in download case and for SMC modem in upload case, SMC modem implements a special format of transferred files over FTP connection. The format proposed "escaping"...
-
Page 31: Mux Operation
MUX Operation The SMC modem cell module is supplied with an internal 3GPP 27.10 protocol stack, also referred to as a multiplexer or MUX. The SMC modem with multiplexer support utility provides the following capabilities: Provides the terminal with up to five virtual channels on one physical RS-232 connection. Provides simultaneous data (CSD/1x data call) and command (AT command set) services. -
Page 32: Smc Modem Module Profiles
In addition to the default profile, you can store an individual one with AT&W. To alternate between the two profiles enter either ATZ (loads user profile) or AT&F (restores factory profile). NOTE: Every ongoing or incoming call will be terminated. Table 8.1: Profile Commands Returns the current parameter setting. -
Page 33: Core At Command Reference Guide
The SMC modem responds to limited commands set when the phone is locked. These commands are referred to as the "Core AT commands". Generally, when the SMC modem is in this state, the following commands available: Table 9.1: Core AT Commands Command Description This command displays a list of all the AT commands supported by the C24. - Page 34 Command Description AT+GMM This command displays the model identification. AT+GMR This command displays the revision identification. AT+GOI Device Identification. AT+GSN This command requests the product serial number identification in Hex format. AT+ICF This command determines the Character Framing. This command controls the operation of Local Flow Control between the terminal AT+IFC and the SMC modem.
-
Page 35: At Command Reference
All modem functions are controlled using the same industry-standard AT commands that are used to control landline modems. A knowledge of all these commands is not required by most users, but are provided here as a reference. AT Command Types There are several types of AT commands as defined in the following list;... -
Page 36: Result Codes
Result Codes After issuing a command, a result code will typically be displayed on the screen to inform you if the command was successful, unsuccessful, improperly formatted, etc. When in the command mode, thirteen possible result codes may be returned. The result codes can be set to display as either digits or words by accessing the Verbose command, ATV. -
Page 37: Hardware Information Commands
Hardware Information Commands The AT Commands described in this section allow the external application to obtain various hardware information from the modems cellular module. Table 10.4: Hardware Information Commands Command Description AT+GCAP This command displays the overall capabilities of the cell module. This command determines how the state of the DCD line relates to the detection AT&C of the received line signal from the distant end. - Page 38 Table 10.6: NAM Programming Commands Commands Description AT+MNAM This command gets or sets the NAM parameters (parameters 1-12 out of 35). AT+MNAM2 This command gets or sets the NAM parameters (parameters 13-22 out of 35). AT+MNAM3 This command gets or sets the NAM parameters (parameters 23-35 out of 35). This command Selects/reads the current active NAM to which the NAM data will AT+SNAM be written/retrieved using AT+MNAM [x].
-
Page 39: Prl And Pri Commands
PRL and PRI Commands The Preferred Roaming List (PRL) is a database residing in a wireless (primarily CDMA) device, such as a cellphone, that contains information used during the system selection and acquisition process. In the case of RUIM-based CDMA devices, the PRL resides on the RUIM. The PRL indicates which bands, sub bands and service provider identifiers will be scanned and in what priority order. -
Page 40: Call Control Commands
Call Control Commands The AT Commands described in this section are related to Mobile Originated (MOC, i.e. outgoing) Calls and Mobile Terminated (MTC, i.e. incoming) Calls. Table 10.12: Call Control Commands Command Description This command places a voice call on the current network when issued from an accessory device. -
Page 41: Short Message Service (Sms) Commands
Short Message Service (SMS) Commands The AT Commands described in this section allow an external application to use the Short Message Service with the modem. Table 10.13: SMS Command Reference Command Description AT+CSMS This command handles the selection of the SMS message service type. This command handles the selection of the preferred storage area for AT+CPMS messages. -
Page 42: Network Related & User Interface Commands
Network Related & User Interface Commands The AT Commands in this section aply to various network and user interface functions and parameters. For futher information, refer to the Motorola C24 AT Command Set document available from Motorola [1]. Table 10.14: Network Commands Command Description This command enables/disables the network status registration... -
Page 43: Tcp/Udp Ip Commands
TCP/UDP IP Commands A brief description of the TCP/UDP IP commands. For futher information, refer to the Motorola C24 AT Command Set document available from Motorola [1]. Table 10.16: TCP/UDP IP Commands Command Description This command creates a wireless PPP connection with the GGSN or CSD AT+MIPCALL service provider and returns a valid dynamic IP for the SMC modem. -
Page 44: Ftp Commands
FTP Commands A brief description of the FTP (File Transfer Protocal) commands. For futher information, refer to the Motorola C24 AT Command Set document available from Motorola [1]. Table 10.17: FTP Commands Command Description This command causes SMC modem to open a FTP connection with a AT+FTPOPEN remote FTP server, based on given parameters. -
Page 45: Gps - Lbs Commands
GPS - LBS Commands A brief description of the GPS commands. Commands in this section may require the use of the second serial UART test pins. For futher information, refer to the Motorola C24 AT Command Set document available from Motorola [1]. Table 10.18: Motorola Binary AT Commands Command Description... -
Page 46: Fota Commands
FOTA Commands A brief description of the FOTA (Firmware update Over The Air) commands. For futher information, refer to the Motorola C24 AT Command Set document available from Motorola [1]. Table 10.20: FOTA Commands Command Description This command enables setting the DM session as Automatic/Non- AT+MFOTACNFG Automatic (i.e. -
Page 47: Specifications
Product specifications are subject to change without notice. General Specifications Interface Connectors: Universal Socket Connectivity LED Indicators: Power & CDMA Connection Antenna Interface: Primary Antenna: MMCX, female, 50 ohms Size: 3.150 x 1.375 x 0.570 in. Weight: 0.8 oz. Power Input: 5VDC ±0.25VDC;... -
Page 48: Mechanical Specifications
Mechanical Specifications The following section describes in detail the exterior dimensions of the SMC-CDMA. All of the drawings below are the approximate actual size. The drawings may be used as layout reference, but it is advised that a physical comparison be made to the modem before proceeding with the mounting process. -
Page 49: Service And Support
Product Warranty, RMA and Contact Information CalAmp guarantees that every SMC-CDMA Cellular Modem will be free from physical defects in material and workmanship for one (1) year from the date of purchase when used within the limits set forth in the Specifications section of this manual. The manufacturer's warranty statement is available in Appendix B. -
Page 50: Appendix A - C R E A T I N G A D I A L - U P N E T W O R K I N G C O N N E C T I On
– – Windows XP Add Standard Windows Modem 001-0004-819 Rev01 Page 50 of 62... - Page 51 001-0004-819 Rev01 Page 51 of 62...
- Page 52 001-0004-819 Rev01 Page 52 of 62...
- Page 53 001-0004-819 Rev01 Page 53 of 62...
-
Page 54: Configuring The Modem
Configuring the Modem 001-0004-819 Rev01 Page 54 of 62... -
Page 55: Create A Dial-Up Networking (Dun) Connection
Create a Dial-Up Networking (DUN) Connection 001-0004-819 Rev01 Page 55 of 62... - Page 56 001-0004-819 Rev01 Page 56 of 62...
- Page 57 001-0004-819 Rev01 Page 57 of 62...
- Page 58 001-0004-819 Rev01 Page 58 of 62...
- Page 59 001-0004-819 Rev01 Page 59 of 62...
- Page 60 001-0004-819 Rev01 Page 60 of 62...
- Page 61 001-0004-819 Rev01 Page 61 of 62...
- Page 62 – – CalAmp warrants to the original purchaser for use ("Buyer") that data telemetry products manufactured by DRL ("Products") are free from defects in material and workmanship and will conform to DRL's published technical specifications for a period of, except as noted below, one (1) year from the date of shipment to Buyer.
