1

PANEL DESCRIPTION

' ' Function display

q TRANSMIT INDICATOR
Appears during PTT on.
w BUSY INDICATOR
Appears while receiving a signal or when the squelch is open.
e KEY LOCK INDICATOR
Appears during key lock function ON.
r AUTO POWER OFF INDICATOR
Appears while the auto power off function is ON. (see p. 15)
t LOW BATTERY INDICATOR
Appears or flashes when battery power has decreased to a specified
level.
y GROUP NUMBER INDICATION
One of 01 to 38 appear while the Group function is turned ON.
u CHANNEL NUMBER INDICATOR
Indicates operating channel number.
i POWER ON INDICATOR
Appears while the power is ON.
o ANSWER BACK INDICATOR (see p. 17)
• Appears when you and your group are in the conversation area.
• Blinks when you or your group is out of the conversation area.
3
q
w
o i
r
e t
y
u
