Specifications - Icom IC-F25SR Instruction Manual

10
D D General
• Frequency coverage
• Mode
• Current drain (at 7.2 V)
• Power supply requirement
• Frequency stability
• Antenna impedance
• Dimensions
• Weight
D D Transmitter
• Output power
• Modulation system
• Max. frequency deviation
• Spurious emissions
• Adjacent channel power
• External mic. connector
41

SPECIFICATIONS

: 446.00625–446.09375 MHz
: 8K50F3E (FM)
: TX (at 0.5 W ERP) 0.4 A approx.
Max. audio
: 7.2 V DC nominal*
(negative ground)
*Specified Icom's battery pack only
: ±2.5 ppm
(–25°C to +55°C)
: 50 nominal
: 53.0(W) 195.0(H) 38.0(D) mm
(Fixed type antenna included)
: Approx. 300 g (including BP-232N)
: 0.5 W ERP
: Variable reactance frequency
modulation
: ±2.5 kHz
: 0.25 µW below 1 GHz
1.00 µW above 1 GHz
: 60 dB
: 3-conductor 2.5 (d) mm/2.2 k
300 mA max.
