Turning Cuddeback On/Installing Batteries - Cuddeback NoFlash Owner's Manual

Figure 4
Figure 5
Battery
4
Figure 7
4/05/06
11:13
AM
Figure 8
STEP 2 - TURNING CUDDEBACK ON
1) Slide the On/off Switch to the OFF position
(figure 4).
2) Remove the Compact Flash Card if it is installed
(figure 5).
3) Install 4 brand new alkaline D cell batteries.
(figure 6).
We recommend Duracell or Energizer brand
batteries only! The red LED will light when
batteries are installed.
4) Slide switch to ON. Do not press any key at
this time.
5) In a few seconds the battery level will be
displayed (figure
few seconds the date & time will be displayed
(figure 8).
6) Install the Compact Flash Card.
TIP - Always remove the Compact Flash Card when remov-
ing or installing batteries. This will make it easier to remove
the battery plate and prevent damage to the card.
TIP - Don't be afraid to press the keys to learn
Cuddeback operation. You can not damage your
Cuddeback by pressing keys. If you need to start
over slide the power switch to OFF, and then back to
ON to restart Cuddeback.
8
7) 1 is weak, 4 is strong. In a
