1.6

SPECIFICATIONS

1.6.1 GENERATOR

Rated Max. Continuous Power Capacity (Watts*)
Rated Voltage
Rated Max. Continuous Load Current (Amps)
120 Volts**
240 Volts
Main Line Circuit Breaker
Phase
Number of Rotor Poles
Rated AC Frequency
Power Factor
Recommended Air Filter
Battery Requirement
at -17.8° C (0° F)
Weight
Output Sound Level @ 23 ft (7m) at full load
Normal Operating Range
* Maximum wattage and current are subject to and limited by such factors as fuel Btu content, ambient temperature, altitude, engine power and condition, etc. Maximum power
decreases about 3.5 percent for each 1,000 feet above sea level; and also will decrease about 1 percent for each 6° C (10° F) above 16° C (60° F) ambient temperature.
** Load current values shown for 120 volts are maximum TOTAL values for two separate circuits. The maximum current in each circuit must not exceed the value stated for 240
volts.

1.6.2 ENGINE

Type of Engine
Number of Cylinders
Rated Horsepower
Displacement
Cylinder Block
Valve Arrangement
Ignition System
Recommended Spark Plug
Spark Plug Gap
Compression Ratio
Starter
Oil Capacity Including Filter
Recommended Oil Filter
Recommended Air Filter
Operating RPM
6
Section 1 — General Information
Air-cooled 11 kW Generators
Model 04916-0
10,000 NG/11,000 LP
120/240
83.3 NG/91.7 LP
41.7 NG/45.8 LP
45 Amp
1
2
60 Hz
1
Part # C8127
Group 26/26R 12 Volts and
525 Cold-cranking Amperes Minimum
495 Pounds
62.2 db (A)
-20°F (-28.8°C) to 104°F (40°C)
Model 04916-0
GT-990
2
30 @ 3,600 rpm
992cc
Aluminum w/Cast Iron Sleeve
Overhead Valves
Solid-state w/Magneto
RC14YC
0.76 mm (0.030 inch)
9.5:1
12Vdc
Approx. 1.7 Qts
Part # 70185
Part # 0C8127
2,700
