Getting started

Telephone base and charger installation

Install the telephone base and charger(s) as shown below.
Make sure that the electrical outlet is not controlled by a wall switch.
If you subscribe to DSL (digital subscriber line) high-speed Internet service
through your telephone line, you must install a DSL filter between the
telephone line cord and the telephone wall jack. The filter prevents noise and
caller ID problems caused by DSL interference. Contact your DSL service
provider for more information about DSL filters.
Charger adapter
Charger
• Use only the power adapters supplied with this product. To order a replacement,
visit our website at www.vtechcanada.com or call 1 (800) 267-7377.
• The power adapters are intended to be correctly oriented in a vertical or
floor mount position. The prongs are not designed to hold the plug in place if
it is plugged into a ceiling, under-the-table or cabinet outlet.
Telephone
base power
adapter
Electrical outlet
not controlled by
a wall switch
Telephone base
Telephone
wall jack
2
If you have
DSL high speed
Internet service,
a DSL filter (not
included) is
required.
Telephone
line cord
