Attaching Cuddeback To A Tree - Cuddeback EXPERT Owner's Manual

Figure 19
Figure 20
TIP - We recommend using a
padlock (not included) to secure
the battery cover. This will assure
that nobody tampers with your
Cuddeback Digital Camera.
STEP 6 -
For best image quality install Cuddeback about 10
feet from the place animals are expected. Attach
Cuddeback to a suitable tree 3 to 4 feet above the
ground
TIP - To determine the detection area you can enable TEST
MODE. Then walk slowly back and forth in front of the cam-
era. The red LED will illuminate when the camera senses
you. The camera will NOT trigger when in TEST MODE.
Cuddeback can sense and record images at distances of 50
Figure 18
feet or more. However, you will get the best image quality if
Cuddeback is set closer to the animals.
There are four ways to attach Cuddeback to a tree.
1) Attach with the supplied Torx® screw (stored on
back of
#25 Torx screwdriver (not supplied)
2) Use a cord or bungee (not supplied) in conjunc-
tion with the eyebolt (supplied) to secure
Cuddeback to a tree.
3) Use a tripod or other device (not supplied)
attached to the socket on the back of the camera.
The socket has standard 1/4-20 threads and is
compatible with most tripods.
4) Use Cuddeback Bear Safe (see page 51 for
details).

ATTACHING CUDDEBACK TO A TREE

(figure 18).
Cuddeback)(figure
13
19). You will need a
(figure 20).
