Specifications - Icom IC-40Jr Instruction Manual

12
GENERAL
• Frequency coverage
• Mode
• Frequency stability
• Frequency resolution
• Power supply requirement: 4.5 V (AA 3) or BP-202
• Current drain
• Battery life (Tx:Rx:Stand-by=1:1:8):
3 Alkaline cells
Optional BP-202
• Operating temp. range
• Number of CTCSS freq.
• Dimensions
(projections not included)
• Weight
TRANSMITTER
• Output power
• Maximum deviation
• Spurious emissions
• Ext. mic. connector
RECEIVER
• Receive system
• Sensitivity
• Selectivity
• Spurious and image rejection: More than 40 dB
• Adjacent Ch. rejection
• Intermodulation rejection : More than 40 dB
• Audio output power
(at 4.5 V DC)
• Ext. speaker connector
All stated specifications are subject to change without notice or obligation.
24

SPECIFICATIONS

: 40 UHF C.R.S. channels
(476.425–477.400 MHz)
: F3E (FM)
: ±3.0 kHz
: 25 kHz
: Less than 500 mA
approx. 28 hours
approx. 10 hours
: 0˚C to +55˚C
: 38
: 55.5(W) 102.5(H) 26.5(D) mm
: 180 g (including 3 AA batteries)
: 500 mW ±20% (at 4.5 V DC)
: Less than ±5.0 kHz
: Less than –30 dBm
: 3-conductor 2.5 (d) mm/2.2 kΩ
: Double-conversion superheterodyne
: Less than 0.2 µV (12 dB SINAD)
: More than 12 kHz/–6 dB
: More than 40 dB
: More than 100 mW at 10% distortion
with an 8 Ω load
: 2-conductor 3.5 (d) mm/8 Ω
