A/V SCALER PRO REMOTE DESCRIPTION
2
4
6
8
1.
Output - Cycles through the available output resolutions. Please see the
section A/V Scaler Pro CONFIGURATION / Output on page 8 for the output
resolution table.
2.
Input - Cycles though all of input sources. The selectable inputs are
Composite, S-Video, Component, HDMI 1, and HDMI 2.
3.
Power - Turns the unit on and off (standby).
4.
Exit - Exits the current menu option and menu system.
5.
Menu - Displays the menu system for adjustment of options.
6.
Navigation Keys - These include up, down, left, and right buttons for
navigating the menu system.
7.
The OK button will select specifi c menu options for adjustment and will also
confi rm/cycle-through selections (Output/Input).
8.
Reset - Resets the input and output resolutions to factory default.
9.
Auto Adjust - Sets the display for optimal resolution and aspect ratio based
on the display's EDID information and the currently selected sources output
resolution.
6
1
3
5
7
9
