Status Commands
These commands are sent in ASCII format.
Command Code
R POWER
R SOURCE
R OUTPUT
R SIZE
R PICTUREMODE
R CONTRAST
R BRIGHTNESS
R HUE
R SATURATION
R SHARPNESS
R NR
R PCHPOSITION
R PCVPOSITION
R PCCLOCK
R PCPHASE
R COLORTEMP
R RED
R GREEN
R BLUE
R OSDHPOSITION
R OSDVPOSITION
R OSDTIMEOUT
R OSDBACKGROUND
R AUDIOMUTE
R AUDIODELAY
RS-232 COMMANDS
Response
> POWER ON
> SOURCE CV~HDMI
> OUTPUT
NATIVE~WUXGA
> SIZE FULL~PANSCAN
> PICTUREMODE
STANDARD~USER
> CONTRAST 0~100
> BRIGHTNESS 0~100
> HUE 0~100
> SATURATION 0~100
> SHARPNESS 0~100
> NR OFF~HIGH
> PCHPOSITION 0~100
> PCVPOSITION 0~100
> PCCLOCK 0~100
> PCPHASE 0~63
> COLORTEMP
NORMAL~USER
> RED 0~100
> GREEN 0~100
> BLUE 0~100
> OSDHPOSITION 0~100
> OSDVPOSITION 0~100
> OSDTIMEOUT 0~100
> OSDBACKGROUND
0~8
> AUDIOMUTE OFF~ON
> AUDIODELAY
OFF~150MS
15
Description
SHOW POWER STATUS
SHOW SOURCE STATUS
SHOW OUTPUT STATUS
SHOW SIZE STATUS
SHOW PICTURE MODE STATUS
SHOW CONTRAST STATUS
SHOW BRIGHTNESS STATUS
SHOW HUE STATUS
SHOW SATURATION STATUS
SHOW SHARPNESS STATUS
SHOW NR STATUS
SHOW PC H-POSITION STATUS
SHOW PC V-POSITION STATUS
SHOW PC COLOK STATUS
SHOW PC PHASE STATUS
SHOW COLOR TEMP STATUS
SHOW COLOR TEMP RED STATUS
SHOW COLOR TEMP GREEN STATUS
SHOW COLOR TEMP BLUE STATUS
SHOW OSD H-POSITION STATUS
SHOW OSD V-POSITION STATUS
SHOW OSD TIMEOUT STATUS
SHOW OSD BACKGROUND STATUS
SHOW AUDIO MUTE STATUS
SHOW AUDIO DELAY STATUS
