Rs-232 Commands - Gefen EXT-GSCALER-PRO EXT-GSCALER-PRO User Manual

Command Code
S OUTPUT 9
S OUTPUT 10
S OUTPUT 11
S OUTPUT 12
S OUTPUT 13
S OUTPUT 14
S OUTPUT 15
S OUTPUT 16
S OUTPUT 17
S OUTPUT 18
S SIZE 0
S SIZE 1
S SIZE 2
S SIZE 3
S SIZE 4
S SIZE 5
S SIZE 6
S PICTUREMODE 0~3
S CONTRAST 0~100
S BRIGHTNESS 0~100
S HUE 0~100
S SATURATION 0~100
S SHARPNESS 0~100
S NR 0~3
S PCHPOSITION 0~100
S PCVPOSITION 0~100
S PCCLOCK 0~100
S PCPHASE 0~63
S COLORTEMP 0~3
S RED 0~100
S GREEN 0~100
S BLUE 0~100
S OSDHPOSITION 0~100
S OSDVPOSITION 0~100
S OSDTIMEOUT 0~100
S OSDBACKGROUND 0~8
S AUDIOMUTE 0~1
S AUDIODELAY 0~3
S RESET 1

RS-232 COMMANDS

Response
> OUTPUT 1080I
> OUTPUT 1080P
> OUTPUT 576I
> OUTPUT 576P
> OUTPUT 720P
> OUTPUT 1080I50
> OUTPUT 1080P50
> OUTPUT WXGA
> OUTPUT WSXGA
> OUTPUT WUXGA
> SIZE FULL
> SIZE OVERSCAN
> SIZE UNDERSCAN
> SIZE LETTERBOX U.S.
> SIZE PANSCAN U.S.
> SIZE LETTERBOX FULL
> SIZE PANSCAN FULL
> PICTUREMODE
STANDARD~USER
> CONTRAST 0~100
> BRIGHTNESS 0~100
> HUE 0~100
> SATURATION 0~100
> SHARPNESS 0~100
> NR OFF~HIGH
> PCHPOSITION 0~100
> PCVPOSITION 0~100
> PCCLOCK 0~100
> PCPHASE 0~63
> COLORTEMP
NORMAL~USER
> RED 0~100
> GREEN 0~100
> BLUE 0~100
> OSDHPOSITION 0~100
> OSDVPOSITION 0~100
> OSDTIMEOUT 0~100
> OSDBACKGROUND
0~8
> AUDIOMUTE OFF~ON
> AUDIODELAY
OFF~150MS
> RESET ON
14
Description
1080I 60HZ RESOLUTION OUTPUT
1080P 60HZ RESOLUTION OUTPUT
576I 60HZ RESOLUTION OUTPUT
576P 60HZ RESOLUTION OUTPUT
720P 50HZ RESOLUTION OUTPUT
1080I 50HZ RESOLUTION OUTPUT
1080P 50HZ RESOLUTION OUTPUT
WXGA RESOLUTION OUTPUT
WSXGA RESOLUTION OUTPUT
WUXGA RESOLUTION OUTPUT
SCALER FULL OUTPUT
SCALER OVERSCAN OUTPUT
SCALER UNDERSCAN U.S. OUTPUT
SCALER LETTERBOX U.S. OUTPUT
SCALER PANSCAN OUTPUT
SCALER LETTERBOX FULL OUTPUT
SCALER PANSCAN FULL OUTPUT
0:STANDARD ; 1:MOVIE ; 2:VIVID ; 3:USER
,PICTURE MODE OUTPUT
CONTRAST 0~100 ADJUST
BRIGHTNESS 0~100 ADJUST
HUE 0~100 ADJUST
SATURATION 0~100 ADJUST
SHARPNESS 0~100 ADJUST
0:OFF ; 1:LOW ; 2:MIDDLE ; 3:HIGH ,NR CONTROL
H POSITION 0~100 ADJUST
V POSITION 0~100 ADJUST
PC MODE COLCK 0~100 ADJUST
PC MODE PHASE 0~63 ADJUST
0:NORMAL ; 1:WARM ; 2:COOL ; 3:USER ,COLOR
TEMP SETTING
COLOR TEMP "RED" ADJUST
COLOR TEMP "GREEN" ADJUST
COLOR TEMP "BLUE" ADJUST
OSD H POSITION 0~100 ADJUST
OSD V POSITION 0~100 ADJUST
OSD TIMEOUT 0~100 SETTING
OSD OSDBACKGROUND 0~8 ADJUST
0:OFF ; 1:ON ,AUDIO MUTE CONTROL
0:OFF ; 1:40MS ; 2:110MS ; 3:150MS ,AUDIO DELAY
SETTING
RESET ACTION
