18 Connection

Connecting multiple displays

You can connect multiple displays serially (daisy chain connection) to a computer for
management. The number of displays you can connect serially depends on the resolution of the
input signal you use.
The first display
RS-232C cable
Additional display
Notes:
• This RS-232C daisy chain connection requires an RS-232C port equipped computer.
• Use RS-232C serial null modem cables for daisy chain connection.
• Avoid using HDCP source for daisy chain connection.
D-Sub (15-pin) cable
AC SWITCH
100-240V~50-60Hz
ON/OFF
1.5A
IN
AC SWITCH
100-240V~50-60Hz
ON/OFF
1.5A
IN
