Planar PS5500 Specifications

The Planar PS5550 is a 55" professional LCD display delivering a full set of commercial-grade features with all the energy
efficiency and design benefits of LED backlighting. The Planar PS5550's ultra-thin, lightweight design offers multiple
connectivity options, low power consumption, and superior visual performance ideal for public signage and corporate
applications. The Planar PS5550 also provides full HD 1080p resolution with advanced features such as automatic/manual
backlight control, video wall support, and RS-232 control. For added protection, the metal bezel improves durability and
reduces heat load on the LCD. The Planar PS5550 is the ideal combination of value, performance, and reliability with the
design and cost benefits of LED technology.
FEATURES
Ultra-thin, lightweight
and eco-friendly
Comprehensive set of
data and video inputs
Durable metal bezel
Wide range of advanced features
for professional applications
PLANAR PS5550
Display resolution
Aspect ratio
Display type
Viewable size
Cabinet dimensions (WxHxD)
Bezel width
Brightness (typical)
Response time (typical)
Frame rate
Contrast ratio (typical)
Full viewing angle
Color gamut
Display weight
Shipping weight
Backlight type
Line voltage
Power consumption (max)
Ambient noise
Operating temperature range
Operating humidity range
Safety regulations
Inputs
Audio input
Audio output
Display control
Auto brightness control
Enclosure
Display orientation
Mounting
Backlight life (1/2 brightness)
Features
Optional accessories
Warranty
**Weight and dimensions are approximate. Specifications and design are subject to change without notice. This product may be subject to export control regulations.
PLANAR PS5550
FHD 1080p (1920x1080)
16:9
LCD Active Matrix Flat Panel Display (TFT)
55" diagonal
49.6" x 28.8" x 2.3" (1259.8mm x 731.9mm x 59.0mm)
1.0" (24mm)
400 cd/m²
6.5 ms
120Hz
4000:1
178°
72% NTSC
59 lbs (27 kg)
73 lbs (33 kg)
Edge-Lit LED
100 - 240V; 50/60Hz
185W
Fanless
0-40°C (32 -104°F)
10-90% RH non-condensing
FCC Class A, UL, CE
HDMI, DVI, VGA, Composite Video, Component Video, S-Video
Phone jack and L/R RCA jack
RCA jack, external speaker connector (10Wx2)
RS-232C in/out, IR Remote Control, Keypad
Ambient light sensor
Metal, industrial
Landscape
VESA: 200x400mm; 4 holes
PC Mounting: 100x200mm; 6 holes
50,000 hours
Video wall support up to 10x10 configuration, on/off
scheduling, carrying handles, picture in picture (PiP),
compliant
Flat wall mount, tilting wall mount, table stand
3-year, 2-day advance replacement
TAA
