Planar PS4200TL Specifications

The Planar PS4200 is a 42" professional LCD display delivering multiple connectivity options, enhanced durability, and
superior visual performance. To meet the requirements of demanding public signage and corporate applications, the
Planar PS4200 provides full HD 1080p resolution with advanced features such as automatic/manual backlight control,
video wall support, RS-232 control, and optional touch screen. For added protection, the metal bezel on the Planar PS4200
improves durability and reduces heat load on the LCD. The Planar PS4200 is the ideal combination of value, performance,
and reliability for any professional large format monitor application.
FEATURES
Comprehensive set of
data and video inputs
Durable metal bezel
Wide range of advanced features
for professional applications
Superior full HD 1080p image
quality with 500 cd/m brightness
2
Optional fully integrated dual touch
PLANAR PS4200
PLANAR PS4200 and PS4200TL
Cabinet dimensions
(WxHxD)
Display weight*
Shipping weight*
Touch technology
Touch interface
OS compatibility
Speakers
Display resolution
Aspect ratio
Display type
Viewable size
Bezel width
Screen brightness (typical)
Response time (typical)
Frame rate
Contrast ratio (full field)
Full viewing angle
Color gamut
Backlight type
Line voltage
Power consumption
Operating temperature range
Operating humidity range
Safety regulations
Standard inputs
Audio input
Audio output
Display control
Auto brightness control
Enclosure
Mounting
Backlight life (1/2 brightness)
Display orientation
Features
Optional accessories
Warranty
*Weight and dimensions are approximate. Specifications and design are subject to change without notice. This product may be subject to export control regulations.
PS4200
39.1" x 23.0"x4.7"
(992.0mm x 585.0mm x 119.6mm)
54 lbs (25 kg)
62 lbs (28 kg)
N/A
N/A
N/A
12W x 2 built-in
FHD 1080p (1920 x 1080)
16:9
LCD Active Matrix Flat Panel Display
42" diagonal
1.1" (29mm)
500 cd/m²
5 ms
60Hz
1500:1
178°
72% NTSC
CCFL (cold cathode fluorescent lamp)
100 - 240V; 50/60Hz
190W (Max)
0-40°C (32 -104°F)
10-90% RH non-condensing
FCC Class A, UL, CE
HDMI, DVI, VGA, Composite Video, Component Video, S-Video
Phone jack and L/R RCA jack
RCA jack, external speaker connector (10W x 2)
RS-232C in/out, IR Remote Control, Keypad
Ambient light sensor
Metal, industrial
VESA: 400 x 200mm; 8 holes
PC Mounting: 100x200mm; 6 holes
50,000 hours
Landscape
Video wall support up to 10x10 configuration, Carrying handles,
On/Off scheduling, Picture-in-Picture (PiP), TAA compliant
Flat wall mount, tilting wall mount, table stand
3-year, 2-day advance replacement
PS4200TL
39.1" x 23.0" x 5.1"
(992.0mm x 585.0mm x 128.9 mm)
68 lbs (31 kg)
71 lbs (32 kg)
Optical Dual Touch
USB
Window XP, Window Vista,
Window 7
N/A
