Planar PS Series 4K Displays
Planar PS Series 4K Displays User Manual
020-1384-00C
User Manual
PS5074K │ PS5074K-N
PS5074KT │ PS5074KT-N
PS5574K │ PS5574K-N
PS5574KT │ PS5574KT-N
PS6574K │ PS6574K-N
PS6574KT │ PS6574KT-N
Page | 1

Advertisement

Table of Contents
loading

Related Manuals for Planar PS5074K

Summary of Contents for Planar PS5074K

  • Page 1 User Manual Planar PS Series 4K Displays PS5074K │ PS5074K-N PS5074KT │ PS5074KT-N PS5574K │ PS5574K-N PS5574KT │ PS5574KT-N PS6574K │ PS6574K-N PS6574KT │ PS6574KT-N Planar PS Series 4K Displays User Manual Page | 1 020-1384-00C...
  • Page 2 Copyright © July 2020 by Planar Systems, Inc. All rights reserved. This document may not be copied in any form without permission from Planar. Information in this document is subject to change without notice. Trademark Credits Windows™ is a trademark of Microsoft Corp.

  • Page 3: Table Of Contents

    Using the Remote Control ....................24 16.1 Locking/Unlocking the OSD Menus ..............27 Basic Remote Functions ..................... 28 17.1 Turning the Display On ..................28 17.2 Turning the Display Off ..................28 Planar PS Series 4K Displays User Manual Page | 3 020-1384-00C...
  • Page 4 PS5074KT ........................... 65 PS5574K ..........................66 PS5574KT ........................... 67 PS6574K ..........................68 PS6574KT ........................... 69 Troubleshooting .......................... 70 Accessing the Planar Technical Support Website ..............71 Index ............................72 Planar PS Series 4K Displays User Manual Page | 4 020-1384-00C...

  • Page 5: Introduction

    For interactive content, multi-touch models are also available. Each Planar PS Series 4K display is excellent for 24x7 operation and supports either landscape or portrait oriented mounting. Planar PS Series 4K displays deliver vibrant ultra-high definition images and messages that captivate the attention of any audience.

  • Page 6: Safety Information

    Introduction 1. Safety Information Before using the Planar PS Series 4K, please read this manual thoroughly to help protect against damage to property, and to ensure personnel safety. • Be sure to observe the following instructions. • For your safety, be sure to observe ALL the warnings detailed in this manual.

  • Page 7: Important Safety Instructions

    9. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles and the point where they exit from any Planar large format LCD display. 10. Only use the attachments/accessories specified by the manufacturer.

  • Page 8: Recommended Usage

    • 55”: PS5574K, PS5574K-N, PS5574KT, PS5574KT-N • 65”: PS6574K, PS6574K-N, PS6574KT, PS6574KT-N Planar recommends turning off the power for 4 hours per day for optimal performance. For complete warranty details, please visit www.planar.com/warranty. Planar PS Series 4K Displays User Manual...

  • Page 9: Important Waste Disposal Information

    Important Waste Disposal Information Please recycle or dispose of all electronic waste in accordance with local, state, and federal laws. Additional resources can be found online at http://www.planar.com/about/green/. The crossed-out wheelie bin symbol is to notify consumers in areas subject to Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU that the product was placed on the market after August 13, 2005 and must not be disposed of with other waste.

  • Page 10: Vesa Mounts, General Description

    Introduction 4. VESA Mounts, General Description VESA mounts are used to secure the Planar PS Series 4K Display. The display can be installed using a variety of VESA mounts available through Planar. If you do not have a VESA mount, and would like to purchase one, contact Planar.

  • Page 11: Cleaning The Display

    If the surface requires additional cleaning, use LCD screen cleaner or LCD wipes, which are available at most electronics stores. • Do not let cleaner seep into the display, as it may cause electrical shock or damage. Planar PS Series 4K Displays User Manual Page | 11 020-1384-00C...

  • Page 12: Package Contents

    One per box. HDMI Cable HDMI cable. AC Power Power cord Cord (US) (US) AC Power Power cord Cord (EU) (EU) IR Extender Receive Cable signals from the remote control. Planar PS Series 4K Displays User Manual Page | 12 020-1384-00C...
  • Page 13 Used to control Control the display (AAA batteries included) Cable Clips Used to clamp and organize the cables. Wi-Fi 2.4G 2dBi Antenna Dipole Antenna Quick Start Quick start Guide guide. Planar PS Series 4K Displays User Manual Page | 13 020-1384-00C...

  • Page 14: Installing The Cable Clips

    6. Installing the Cable Clips Use the cable clips included in the Accessory Kit to assist with cable management. These clips snap into place in the locations shown in the image below. Planar PS Series 4K Displays User Manual Page | 14 020-1384-00C...

  • Page 15: Standard Inputs

    Package Contents 7. Standard Inputs Planar PS Series 4K Displays User Manual Page | 15 020-1384-00C...

  • Page 16: Installing The Display

    Back brace • Stud finder (if hanging display on a wall) • Planar PS 4K Series handle accessory (sold separately. Part Number: 998-1876-xx) Other Things You May Need • LCD screen cleaner or LCD wipes - available at most electronics stores •...

  • Page 17: Prepare Your Installation Location

    4K @ 50/60Hz: 5m (15 ft) maximum • 4K @ 24/25/30Hz: 15m (50 ft) maximum • 1080p @ 60Hz and lower resolutions: 20m (65 ft) maximum DisplayPort • 8m (25 ft) maximum Planar PS Series 4K Displays User Manual Page | 17 020-1384-00C...

  • Page 18: Operating The Display

    Menu Down  Menu Up − Menu Left / Decrease value / Volume - Menu Right / Increase value / Volume + SOURCE Source Selection MENU Menu Open / Close Planar PS Series 4K Displays User Manual Page | 18 020-1384-00C...

  • Page 19: Remote Control Receiver

    The remote control receiver is located on a module on the rear side of the display. Pull down the module to provide front facing sensor visibility. See the drawing below for reference. Use the IR extender cable to improve remote control distance and angular performance. Planar PS Series 4K Displays User Manual Page | 19 020-1384-00C...

  • Page 20: Installing Ir Extender

    The position of the IR extender will affect the reception of the IR signal. To ensure the best IR reception, P1 and P2, the two positions marked in the figure below, are recommended for installing the IR extender. Planar PS Series 4K Displays User Manual Page | 20 020-1384-00C...

  • Page 21: Led Indicators

    The LED indicator light is located at the bottom left side of the display. The following table explains what the different colors and blink patterns mean. LED On Power Status Condition Green Power on; Normal operation Power save mode Power off AC off Planar PS Series 4K Displays User Manual Page | 21 020-1384-00C...

  • Page 22: Using The Display In Portrait Mode

    Installations where the display is tilted downward or upward at an angle may also be prone to these issues and are not recommended. Note: Failure to follow these instructions will void the warranty. Planar PS Series 4K Displays User Manual Page | 22 020-1384-00C...

  • Page 23: Using The Touch Screen

    15. Using the Touch Screen You can use the touch screen to control your Windows, Mac or Linux operating system. The Planar PS Series 4K is HID compliant, delivering up to 20 points of touch on both Windows and Linux without a driver.

  • Page 24: Using The Remote Control

    Operating the Display 16. Using the Remote Control Below is a picture of the remote control and its corresponding Hex codes. Planar PS Series 4K Displays User Manual Page | 24 020-1384-00C...
  • Page 25 0x08F7D02F Blue button (function varies) 2295 0x08F7CB34 Rewind content to the beginning 2295 0x08F7CA35 Fast forward content to the end REPEAT 2295 0x08F7C936 Repeat content 2295 0x08F7C837 Not used Planar PS Series 4K Displays User Manual Page | 25 020-1384-00C...
  • Page 26 Key Name Address Data NEC Data Description ▶ 2295 0x08F7C738 Play or pause content ◼ 2295 0x08F7C639 Stop content ⏪ 2295 0x08F7C53A Rewind content ⏩ 2295 0x08F7C43B Fast forward content Planar PS Series 4K Displays User Manual Page | 26 020-1384-00C...

  • Page 27: Locking/Unlocking The Osd Menus

    EXIT, ENTER and EXIT. To unlock it, simply follow the same sequence. Depending on whether you locked or unlocked the menu, you will see one of the following messages on the screen. Planar PS Series 4K Displays User Manual Page | 27 020-1384-00C...

  • Page 28: Basic Remote Functions

    , , , and ENTER to navigate through the menus and 2. Within the menu, use adjust options. 3. Press MENU to return to the previous menu. To exit the menu system, press EXIT. Planar PS Series 4K Displays User Manual Page | 28 020-1384-00C...

  • Page 29: Input Menu

     Select the input source to be displayed at power up. Selecting Last Input will cause the last selected input to be used as the power up source.  Options: Last Input, VGA, HDMI1, HDMI2, DP, Android, Web Browser, Android APP  Default: Last Input Planar PS Series 4K Displays User Manual Page | 29 020-1384-00C...

  • Page 30: Picture Menu

     Increase or decrease the green hue. Press  or  to select the desired level.  Range: 0~100  Default: 50 Saturation  Adjust the brilliance and brightness. Press  or  to select the desired level. Planar PS Series 4K Displays User Manual Page | 30 020-1384-00C...
  • Page 31  Adjust the zoom (overscan) of the image  Options: 0~10  Default: 0 HDMI Color Range  Select RGB range for HDMI and DisplayPort sources  Options: Auto, 0~255, 16~235  Default: Auto Planar PS Series 4K Displays User Manual Page | 31 020-1384-00C...

  • Page 32: Picture Menu - Color Control Submenu

     Adjust the amount of green in dark content  Range: 0~256  Default: 128 Blue Offset  Adjust the amount of blue in dark content  Range: 0~256  Default: 128 Planar PS Series 4K Displays User Manual Page | 32 020-1384-00C...

  • Page 33: Audio Menu

    Audio Source  Select the audio source that is played through the display’s internal speakers, audio out and digital audio out.  Options: Default, Audio In  Default: Default Planar PS Series 4K Displays User Manual Page | 33 020-1384-00C...

  • Page 34: Osd Settings Menu

    Options: Off, 5 sec, 10 sec, 20 sec, 30 sec, 60 sec  Default: 30 sec OSD Rotation  Rotate the OSD for use in either landscape or portrait orientation.  Options: Landscape, Portrait  Default: Landscape Planar PS Series 4K Displays User Manual Page | 34 020-1384-00C...
  • Page 35 Select whether to display the Android navigation bar at startup and when swiping up from the bottom. Use the touch screen or a USB mouse to perform the swipe.  Options: On, Off  Default: On Planar PS Series 4K Displays User Manual Page | 35 020-1384-00C...

  • Page 36: Setup Menu

     Range: 0~100 Clock  Adjust the clock of the displayed signal (VGA source only). Press  or  to select the desired level.  Range: 0~100 Planar PS Series 4K Displays User Manual Page | 36 020-1384-00C...
  • Page 37  Change the time format to a 24-hour format.  Options: On, Off  Default: Off Date Format  Select the desired date format.  Options: month/day/year, day/month/year, year/month/day Planar PS Series 4K Displays User Manual Page | 37 020-1384-00C...
  • Page 38  Use the arrow keys to specify the on and off times Workdays  Select the power on/off time for Monday–Friday, Saturday, and Sunday  Options: Disable, Enable  Use the arrow keys to specify the on and off times. Planar PS Series 4K Displays User Manual Page | 38 020-1384-00C...
  • Page 39 Operating the Display Everyday  Select the power on/off time for Monday–Sunday  Options: Disable, Enable  Use the arrow keys to specify the on and off times. Planar PS Series 4K Displays User Manual Page | 39 020-1384-00C...

  • Page 40: Advanced Setup Menu

     Note: RS232 and LAN functionality will not work in standby mode if Standby Mode is selected. Use another Power Saving Config selection if RS232 or LAN support is needed. Planar PS Series 4K Displays User Manual Page | 40 020-1384-00C...
  • Page 41  Options: No, Yes  Default: No Firmware Update (USB)  Plug in the USB flash drive and select Yes to proceed with firmware update.  Options: No, Yes  Default: Yes Planar PS Series 4K Displays User Manual Page | 41 020-1384-00C...

  • Page 42: Communication Menu

    This menu configures the display’s RS-232 and Ethernet communication ports. Baud rate  Select the baud rate of the display’s RS-232 port  Options: 115200, 38400, 19200, 9600  Default: 19200 LAN Configuration Planar PS Series 4K Displays User Manual Page | 42 020-1384-00C...
  • Page 43 Default: 0.0.0.0  Subnet Mask 。 Set subnet mask 。 Options: 255.255.255.255 。 Default: 0.0.0.0  Default 。 Set gateway address 。 Options: 255.255.255.255 。 Default: 0.0.0.0  First DNS Planar PS Series 4K Displays User Manual Page | 43 020-1384-00C...
  • Page 44 Use this menu to enter the Simple Mail Transfer Protocol (SMTP) server settings. Ask your network administrator or ISP to provide the correct settings for the following fields. 。 Options: On, Off Planar PS Series 4K Displays User Manual Page | 44 020-1384-00C...
  • Page 45 Default: SSL  Port 。 The port for the SMTP connection. Typically, this is port 465.  Manager Email 。 Specify the email address that will receive notifications. SNMP Configuration Planar PS Series 4K Displays User Manual Page | 45 020-1384-00C...
  • Page 46 Specify the destination IP address for the SNMP trap receiver 。 Default: 255.255.255.255  Trap UDP 。 Specify the UDP port for SNMP trap receiver connections 。 Default: 162 Planar PS Series 4K Displays User Manual Page | 46 020-1384-00C...
  • Page 47 Select the TCP port for network connections  Default: 23 Ethernet MAC  Show the MAC address of the display WiFi MAC  Show the WiFi address of the display Planar PS Series 4K Displays User Manual Page | 47 020-1384-00C...

  • Page 48: Information Menu

    Operating the Display 25. Information Menu This read-only menu provides information on the active sources and the latest firmware version. Planar PS Series 4K Displays User Manual Page | 48 020-1384-00C...

  • Page 49: Osd Android Settings Menu

    To access the Android menu, open the Input menu and select Android. Note: In addition to the IR remote control, use the touchscreen or a USB keyboard and mouse to navigate the Android menu and modify settings. Planar PS Series 4K Displays User Manual Page | 49 020-1384-00C...

  • Page 50: Apps

    The default app name will be displayed on the OSD Information Menu (see page 47).  By default, the input source of Android App will allow the default app to be automatically Planar PS Series 4K Displays User Manual Page | 50 020-1384-00C...

  • Page 51: Files

    Allows management of the internal file system and any drives connected via USB. 27. Media Player The Planar PS Series 4K display has an embedded Media Player that can be used to play videos, photos and/or music from a USB Drive. Please see below for more information.
  • Page 52 Media Player Image Compatibility Format File Types Max Resolution JPEG (JFIF 8192 x 8192 file format 1.2) JPEG 8192 x 8192 8192 x 8192 (8 bits) 4096 x 8192 (16 bits) Planar PS Series 4K Displays User Manual Page | 52 020-1384-00C...

  • Page 53: Main Menu

    Compose section on page 53.  The content will play in the order selected during content creation, and with the features selected in the Settings menu. Planar PS Series 4K Displays User Manual Page | 53 020-1384-00C...
  • Page 54 SD card  Photos must be in the following folder: /planar/photo  Videos must be in the following folder: /planar/video  Audio files must be in the following folder: /planar/music Planar PS Series 4K Displays User Manual Page | 54...
  • Page 55 。 After saving the playlist, background music can be added.  Note: This option is displayed after saving a playlist (see image below). 。 Back: Close the sidebar menu. Planar PS Series 4K Displays User Manual Page | 55 020-1384-00C...
  • Page 56 Options: Repeat Once (display each file once), Repeat All (repeat showing all 。 files) 。 Default: Repeat All  Slideshow Effect 。 Select the transition type that occurs when switching from one image to another Planar PS Series 4K Displays User Manual Page | 56 020-1384-00C...
  • Page 57 Options: 5s, 10s, 15s, 20s 。 Default: 5s  Playback Hint 。 Display the file name as the caption below the image while playing it 。 Options: On, Off 。 Default: Off Planar PS Series 4K Displays User Manual Page | 57 020-1384-00C...

  • Page 58: External Control

    External Control In addition to using the Planar PS Series 4K remote control and display, there are other methods of controlling the Planar PS Series 4K display externally: • Using a serial link to send binary commands and to receive responses to those commands.

  • Page 59: Signal Compatibility

    VESA CVT 1680x1050 59.954 65.290 146.250 x x VESA CVT 1920x2160 60.000 135.000 297.000 x CEA-861-F, VIC 16, with vertical parameters doubled 1920x2160 59.988 133.293 277.250 x VESA CVT-R Planar PS Series 4K Displays User Manual Page | 59 020-1384-00C...
  • Page 60 CEA-861-F Format 97, 4:2:0 sub-sampling 3840x2160 135.000 594.000 CEA-861-F Format 97 4096x2160 54.000 297.000 x CEA-861-F Format 98 4096x2160 56.250 297.000 x CEA-861-F Format 99 4096x2160 67.500 297.000 x CEA-861-F Format 100 Planar PS Series 4K Displays User Manual Page | 60 020-1384-00C...

  • Page 61: Color Subsampling Support

    Color Subsampling Support RGB 4:4:4 YUV 4:4:4 YUV 4:2:2 YUV 4:2:0 Video Timing Input Supported Supported Supported Supported 4K @ HDMI 1-4 50/60Hz All Other Supported Timings Planar PS Series 4K Displays User Manual Page | 61 020-1384-00C...

  • Page 62: Specifications

    (1148.4mm x (1245.2mm x (1262.4mm x (1462.6mm x (1481.5mm x Dimensions 655.8mm x 669mm x 718.5mm x 733mm x 843.3mm x 856.4mm x 69.9mm) 87.3mm) 69mm) 86.4mm) 70mm) 85.8mm) Planar PS Series 4K Displays User Manual Page | 62 020-1384-00C...
  • Page 63 Min -4°F ~ Max 140°F (-20°C ~ 60°C) Temperature Operating Min 32°F ~ Max 104°F (0-40°C) at up to 3000 m Temperature Humidity 20-85% RH Approvals FCC Class A, cTUVus, CE Planar PS Series 4K Displays User Manual Page | 63 020-1384-00C...

  • Page 64: Dimensions

    Dimensions PS5074K, PS5074K-N Planar PS Series 4K Displays User Manual Page | 64 020-1384-00C...

  • Page 65: Ps5074Kt

    Dimensions PS5074KT, PS5074KT-N Planar PS Series 4K Displays User Manual Page | 65 020-1384-00C...

  • Page 66: Ps5574K

    Dimensions PS5574K, PS5574K-N Planar PS Series 4K Displays User Manual Page | 66 020-1384-00C...

  • Page 67: Ps5574Kt

    Dimensions PS5574KT, PS5574KT-N Planar PS Series 4K Displays User Manual Page | 67 020-1384-00C...

  • Page 68: Ps6574K

    Dimensions PS6574K, PS6574K-N Planar PS Series 4K Displays User Manual Page | 68 020-1384-00C...

  • Page 69: Ps6574Kt

    Dimensions PS6574KT, PS6574KT-N Planar PS Series 4K Displays User Manual Page | 69 020-1384-00C...

  • Page 70: Troubleshooting

    Perform the adjustments according to "Operating the Display" on page 18. • If the problem you are experiencing is not described below, or you cannot correct the problem, stop using the display and contact Planar’s Technical Support Department. See "Accessing the Planar Technical Support Website" on page 69. Issue Check for the following Make sure the correct source is selected.

  • Page 71: Accessing The Planar Technical Support Website

    Technical Support Website Go to http://www.planar.com/support/ to locate the following support documents and resources: • User Guide • RS232 User Manual • Standard Warranties • Planar support hotline number and email Planar PS Series 4K Displays User Manual Page | 71 020-1384-00A...

  • Page 72: Index

    47 Volume, 18, 28, 33 Input Menu, 29 Installing the Display, 16 Warranty Coverage, 8 What is Temporary Image Retention? LED Indicators, 21 Image Retention, 8 Locking, 27 Planar PS Series 4K Displays User Manual Page | 72 020-1384-00A...
