  • Page 1 SuperServer ® ARS-211ME-FNR USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...
  • Page 4 Preface Contents Contacting Supermicro ......................8 Chapter 1 Introduction 1.1 Overview ..........................9 1.2 System Features ........................10 Front View .........................10 Drive Carrier Indicators ....................11 Control Panel ........................12 Rear View ..........................13 Power Supply Indicator ....................13 1.3 System Architecture ......................14 Main Components ......................14 System Block Diagram ......................15 1.4 Motherboard Layout ......................16...
  • Page 5 Preface 2.5 Installing the Chassis into a Rack ..................26 Removing the Chassis from the Rack ................27 Chapter 3 Maintenance and Component Installation 3.1 Removing Power .......................28 3.2 Accessing the System ......................29 3.3 Static-Sensitive Devices .....................30 Precautions ........................30 Unpacking .........................30 3.4 Processor and Heatsink Installation ...................31 The AmpereOne Processor ....................31 Overview of the Processor Socket ..................32 Overview of the Heatsink ....................32...
  • Page 6 System Boot Failure ......................72 Memory Errors ........................72 Losing the System's Setup Configuration .................73 If the System Becomes Unstable ..................73 6.3 Technical Support Procedures ...................74 6.4 Frequently Asked Questions ....................75 6.5 Returning Merchandise for Service ..................76 6.6 Feedback ..........................76 6.7 Contacting Supermicro .......................77...
  • Page 7 Preface Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications Appendix C BIOS Codes Appendix D Updating BIOS and BMC with OpenBMC WebGUI...
  • Page 8 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
  • Page 9 2U Rackmount, 3.5" x 17.2” x 17” (88.9 x 436.88 x 431.8 mm) (H x W x D) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the ARS-211ME-FNR have been certified as...
  • Page 10 Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Storage Drives Micro USB Port UID Button USB3.0 Ports (2) 25 GbE SFP28 Ports (2) Control Panel VGA Port Dedicated LAN Port...
  • Page 11 Chapter 1: Introduction Expansion Slots Slot Description PCIe 5.0 x16 (FHHL) PCIe 5.0 x16 DW GPU PCIe 5.0 x16 (LP) PCIe 5.0 x8 (FHHL) PCIe 5.0 x8 (cannot be used if DW GPU installed in slot 2) (FHFL) PCIe 5.0 x16 AIOM Drive Carrier Indicators Each drive carrier has two LED indicators: an activity indicator and a status indicator.
  • Page 12 Chapter 1: Introduction Control Panel Power Button UID Button Drive Activity LED Power LED NIC2 LED NIC1 LED Power Fail LED Information LED Figure 1-2. Control Panel Control Panel Features Feature Description The main power switch applies or removes primary power from the power supply to the Power Button server but maintains standby power.
  • Page 13 Indicates that the power supply has a warning condition and continues to operate. Indicates that the power supply is plugged in, and is in an abnormal state. The Solid Amber system might need service. Please contact Supermicro technical support. No AC power to modules...
  • Page 14 Chapter 1: Introduction 1.3 System Architecture This figure below shows the locations of the main system components and a system block diagram. Main Components Fans Power Supply Modules Processor DIMM Slots Six Drive Bays Figure 1-4. Main Component Locations System Features: Top Feature Description Power Supply...
  • Page 15 Chapter 1: Introduction System Block Diagram The block diagram below shows the connections and relationships between the subsystems and major components of the overall system. DIMM1 DIMM2 DIMM1 DIMM2 DIMM1 DIMM2 DIMM1 DIMM2 DIMM2 DIMM1 DIMM2 DIMM1 DIMM2 DIMM1 DIMM2 DIMM1 CH 0/1/2/3 CH7/6/5/4 AmpereOne...
  • Page 16 Chapter 1: Introduction 1.4 Motherboard Layout Below is a layout of the R13SPD motherboard with a jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4 or the Motherboard...
  • Page 17 Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting (*) JONEX1 AmpereOne AC03/AmpereOne AC04 Voltage Closed (AmpereOne AC04 CPU) UID/Reset Button Switch Pins 2–3 (UID) Description Status Unit Identifier LED Solid Blue: Unit Identified Red: Standby System Status LED Green: System Power Top LED Yellow: 10 G Link LED_L1...
  • Page 18 Chapter 1: Introduction Connector Description USB5/6 (2.0) Front-Accessible USB 2.0 Header JVGA1 VGA Port...
  • Page 19 Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those specific components.
  • Page 20 Chapter 2: Server Installation Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them. • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together.
  • Page 21 Chapter 2: Server Installation Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.
  • Page 22 Chapter 2: Server Installation 2.4 Installing the Rails This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided.
  • Page 23 Chapter 2: Server Installation Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the chassis from coming completely out of the rack when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. 1.
  • Page 24 Chapter 2: Server Installation Installing the Inner Rails Begin the rack mounting procedure by installing the inner rails to the chassis. 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks in the chassis with the inner rail's.
  • Page 25 Chapter 2: Server Installation Installing the Outer Rails onto the Rack 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. Hang the hooks on the front of the outer rail onto the square holes on the front of the rack.
  • Page 26 Chapter 2: Server Installation 2.5 Installing the Chassis into a Rack Once rails are attached to the chassis and the rack, you can install the server. 1. Pull the middle rail out of the front of the outer rail and make sure that the ball bearing shuttle is locked at the front of the middle rail.
  • Page 27 Chapter 2: Server Installation Removing the Chassis from the Rack Caution! It is dangerous for a single person to off-load the heavy chassis from the rack without assistance. Be sure to have sufficient assistance supporting the chassis when removing it from the rack.
  • Page 28 Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.
  • Page 29 Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The CSE-LB23MTS-R000NDP chassis features a removable top cover, which allows easy access to the inside of the chassis. Removing the Top Cover 1. Remove the screw on each side of the chassis. 2.
  • Page 30 Chapter 3: Maintenance and Component Installation 3.3 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect the system PCBs from ESD. Precautions •...
  • Page 31 When installing the processor and heatsink, ensure a torque driver set to the correct force is used for each screw. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustrations only. Your components may look different.
  • Page 32 Chapter 3: Maintenance and Component Installation Overview of the Processor Socket The processor socket is protected by a plastic protective cover and pre-installed with a processor carrier. Plastic Protective Cover Processor Carrier LGA5964 Socket Overview of the Heatsink The heatsink is attached to the processor after the processor is secured in the LGA5964 socket.
  • Page 33 Chapter 3: Maintenance and Component Installation Installing the Processor 1. Use a screwdriver with a T20 bit to unscrew the socket force frame. Unscrew counterclockwise in the sequence 6-5-4-3-2-1. The screws are numbered on the socket force frame next to each screw hole. Screw #3 Screw #1 Screw #6...
  • Page 34 Align pin 1 on the processor with pin 1 location on the carrier. Note: The carrier (Part Number: SKT-1537H-0000-FXC) will either be shipped with the system or accompany the CPU. If the carrier is not included, please contact Supermicro. Pin 1...
  • Page 35 Chapter 3: Maintenance and Component Installation 5. Turn over the processor carrier assembly with the top side facing up. 6. Align the processor pad cutout on the corner to the bottom-right corner of the socket. Also align the carrier's mounting holes with the respective screw holes on the socket.
  • Page 36 Chapter 3: Maintenance and Component Installation 7. Remove the plastic protective cover from the socket force frame. 8. Using a torque driver set to a force of 12±1 in-lbf (1.242-1.469 N-m) with a T20 bit to screw in the socket force frame. Tighten the screws clockwise in the sequence 1-2-3-4- 5-6.
  • Page 37 Chapter 3: Maintenance and Component Installation Installing the Heatsink 1. After the processor is secure, you must install the heatsink to the socket frame. Ensure a proper amount of thermal grease is applied to the heatsink. Lower the heatsink down until the four screws on the heatsink align with the four screw holes on the socket frame.
  • Page 38 Chapter 3: Maintenance and Component Installation 3. When finished, the heatsink will be secured over the socket and processor.
  • Page 39 Chapter 3: Maintenance and Component Installation 3.5 Motherboard Installation All motherboards have standard mounting holes to fit different types of chassis. Make sure that the locations of all the mounting holes for both the motherboard and the chassis match. Although a chassis may have both plastic and metal mounting fasteners, metal ones are highly recommended because they ground the motherboard to the chassis.
  • Page 40 Chapter 3: Maintenance and Component Installation Installing the Motherboard 1. Install the I/O shield into the back of the chassis, if applicable. 2. Locate the mounting holes on the motherboard. See the previous page for the location. 3. Locate the matching mounting holes on the chassis. Align the mounting holes on the motherboard against the mounting holes on the chassis.
  • Page 41 Chapter 3: Maintenance and Component Installation 3.6 Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing memory modules to prevent any possible damage. Memory Support The R13SPD motherboard supports up to 8 TB of DDR5 ECC RDIMM/3DS RDIMM memory with speeds of up to up to 5200 MT/s in 16 memory slots (2DPC).
  • Page 42 Chapter 3: Maintenance and Component Installation General Guidlines for Optimizing Memory Performance • DIMM slots must be populated in the following order: DIMMA1, DIMMB1, DIMMC1, DIMMD1, DIMME1, DIMMF1, DIMMG1, DIMMH1, and then DIMMA2, DIMMB2, DIMMC2, DIMMD2, DIMME2, DIMMF2, DIMMG2, DIMMH2. •...
  • Page 43 Chapter 3: Maintenance and Component Installation DIMM Installation COM1 JUIDB1 MH12 JVGA1 USB3/4 1. Insert DIMM modules in the following BMC_LAN USB1/2 LAN2 LAN1 USB5/6 LEDM2 order: DIMMA1, DIMMB1, DIMMC1, MH13 DIMMD1, DIMME1, DIMMF1, DIMMG1, DIMMH1, and then DIMMA2, DIMMB2, CPU AIOM PCIe 5.0 x16 (OCP 3.0) MH14...
  • Page 44 Chapter 3: Maintenance and Component Installation 3.7 Motherboard Battery Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock outwards to unlock it.
  • Page 45 The CSE-LB23MTS-R000NDP chassis supports up to six 2.5" storage drives in drive carriers to simplify their removal from the chassis. These carriers also help promote proper airflow. Note: Enterprise level storage drives are recommended for use in Supermicro chassis and servers.
  • Page 46 Chapter 3: Maintenance and Component Installation Installing Drives Removing Drive Carriers from the Chassis 1. Push the release button on the drive carrier. This releases and extends the drive carrier handle. 2. Use the handle to pull the carrier out of the chassis as shown below. Caution: Except for short periods of time (swapping drives), to ensure proper airflow do not operate the server with the drive carriers removed from the bays, regardless of how many drives are installed.
  • Page 47 Chapter 3: Maintenance and Component Installation Installing a Tooless 2.5" Storage Drive 1. Place the empty storage drive carrier on a flat surface. 2. Retract the blue clips on the side of the carrier. 3. Insert a 2.5" storage drive at an angle into the carrier so that the mounting screw holes on the right side of the drive align with two stubs in the drive carrier.
  • Page 48 Chapter 3: Maintenance and Component Installation Installing M.2 Solid State Drives The system can accommodate one M.2 solid state drive in the 22110 form factor. Installing the M.2 SSD Caution: Use industry-standard anti-static equipment, such as gloves or wrist strap, and follow precautions to avoid damage caused by ESD.
  • Page 49 Chapter 3: Maintenance and Component Installation 3.9 Expansion Cards The system can accommodate two low-profile and up to eight full-length, full-height PCIe cards. Installing a low-profile Expansion Card 1. Power down the system and remove the cover. 2. In the rear of the chassis, remove the blank PCIe slot assembly as shown. 3.
  • Page 50 Chapter 3: Maintenance and Component Installation 3.10 GPUs Installing a GPU Expansion Card (Rear of Chassis) 1. Power down the system and remove the cover. 2. At the rear of the chassis, remove the blank PCIe slot GPU bracket assemblies as shown.
  • Page 51 Chapter 3: Maintenance and Component Installation 3. Slide a PCIe (GPU) expansion card into the GPU bracket slot, aligning it with the PCIe slot. GPU and GPU Bracket 4. Reinstall the GPU bracket with the installed expansion card into the rear of the chassis, and secure it with a screw.
  • Page 52 Chapter 3: Maintenance and Component Installation 3.11 System Cooling System Fans Four hot-swap fans provide cooling and can be replaced without powering down the system. Fan speed is controlled by a system temperature setting in IPMI. If a fan fails, the remaining fans will ramp up to full speed.
  • Page 53 Chapter 3: Maintenance and Component Installation Air Shrouds An air shroud concentrates airflow to maximize fan efficiency. It covers the processors and heatsinks. Installing the Air Shroud The air shroud fits on top of the motherboard. Align the pins and press the plastic air shroud into the chassis along the edges.
  • Page 54 3.12 Power Supply The system features redundant power supplies. The power modules can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120 V or 180-240 V.
  • Page 55 Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 56 Chapter 4: Motherboard Connections Proprietary PSU 8-Pin Power Connectors JPWR3 and JPWR11 are proprietary 8-pin power supply connectors. These power connections are required. Proprietary PSU 8-pin Connector Pin Definitions Pin# Definition 1 – 4 Ground 5 – 8 +12 V Required Connection Power Connector for Special Riser Card JPWR7 is a 5 V/12 V 4-pin power connector for riser cards.
  • Page 57 Chapter 4: Motherboard Connections 4.2 Headers and Connectors Fan Headers There are six 6-pin fan headers on the motherboard. Although pins 1-3 of the fan headers are backward compatible with traditional 3-pin fans, use fans with support for Pulse Width Modulation to allow the fan speeds to be automatically adjusted based on the motherboard temperature.
  • Page 58 The motherboard features one Advanced I/O Module (AIOM) PCIe 5.0 x16 slot, which can connect to an OCP 3.0 mezzanine card. Visit the Supermicro website for all available module options. Power must be unplugged prior to removing or installing an AIOM module card.
  • Page 59 A Trusted Platform Module (TPM) header is located at JTPM1 to provide TPM support. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: https://www. supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions Pin#...
  • Page 60 JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 61 Chapter 4: Motherboard Connections Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. Refer to the table below for pin definitions. Power Button Pin Definitions (JF1) Pin# Definition Signal...
  • Page 62 Chapter 4: Motherboard Connections NIC1/NIC2 (LAN1/LAN2) The Network Interface Controller (NIC) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.
  • Page 63 Chapter 4: Motherboard Connections 4.3 Input/Output Ports See figure below for the locations and descriptions of the various I/O ports on the I/O panel of the motherboard. COM1 JUIDB1 MH12 JVGA1 USB3/4 BMC_LAN USB1/2 LAN2 LAN1 USB5/6 LEDM2 MH13 CPU AIOM PCIe 5.0 x16 (OCP 3.0) MH14 CPU SLOT9 PCIe 5.0 x16...
  • Page 64 Chapter 4: Motherboard Connections Dedicated BMC LAN Port A dedicated BMC LAN port is near the VGA port on the rear I/O ports. BMC LAN Pin Definition Pin# Definition Pin# Definition Yellow LED- (Activity) Yellow LED+ (Activity) Amber LED+ (1 GbE Link)/Green LED- Green LED+ (100 MbE Link)/Amber LED+ VGA Port A video (VGA) port is included with the rear I/O ports.
  • Page 65 The UID Indicator provides easy identification of a system unit that may be in need of service. Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, refer to the IPMI User's Guide posted on our website at https://www.supermicro.com/support/ manuals/. UID Switch...
  • Page 66 Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 67 Chapter 4: Motherboard Connections UID/Reset Button Switch Jumper JP2 controls the function of the UID/Reset Button. Refer to the table below for jumper settings. The default setting is UID. UID/Reset Button Switch Jumper Settings Jumper Setting Definition Pins 1–2 Reset Button Pins 2–3 UID Button (Default) AmpereOne AC03/AmpereOne AC04 Voltage...
  • Page 68 Chapter 4: Motherboard Connections 4.5 LED Indicators System Status LED LED6 is the system status LED for the motherboard. When the system is plugged into power, LED6 will indicate the status of the system. System Status LED Color/State Definition Solid Red Standby Solid Green System Power...
  • Page 69 When logging in to the BMC for the first time, please use the unique password provided by Supermicro to log in. You can change the unique password to a user name and password of your choice for subsequent logins.
  • Page 70 Chapter 6: Troubleshooting and Support Chapter 6 Troubleshooting and Support 6.1 Information Resources Website A great deal of information is available on the Supermicro website. Figure 6-1. Supermicro Website • Specifications for servers and other hardware are available by clicking Products. •...
  • Page 71 Security Center for recent security notices Supermicro Phone and Addresses 6.2 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the...
  • Page 72 Chapter 6: Troubleshooting and Support No Video 1. If the power is on, but you have no video, remove all add-on cards and cables. 2. Use the speaker to determine if any beep codes are present. Refer to Appendix A details on beep codes.
  • Page 73 Chapter 6: Troubleshooting and Support 4. Check for bad DIMM modules or slots by swapping a single module among all memory slots and check the results. Losing the System's Setup Configuration 1. Make sure that you are using a high-quality power supply. Always replace power supplies with the exact same model that came with the system.
  • Page 74 Before contacting Technical Support, please take the following steps. Also, note that as a motherboard manufacturer, Supermicro also sells motherboards through its channels, so it is best to first check with your distributor or reseller for troubleshooting services. They should know of any possible problems with the specific system configuration that was sold to you.
  • Page 75 Note: The SPI BIOS chip used on this motherboard cannot be removed. Send your motherboard back to our RMA Department at Supermicro for repair. For BIOS Recovery instructions, refer to the AMI BIOS Recovery Instructions posted at https://www.supermicro.
  • Page 76 During the warranty period, contact your distributor first for any product problems. 6.6 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. To provide feedback on our manuals, please email us at techwriterteam@ supermicro.com.
  • Page 77 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
  • Page 78 Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
