This is the process to auto-upgrade firmware on the 9600IP:
•
Plug a phone in to one or multiple ports of the 24-port POE switch connected to the PC
running DHCP/TFTP (tftpd32.exe)
•
Wait for the warble tone (doodle doodle)
•
Press 3333 # to get config file from DHCP/TFTP (Option 66 Configured in TFTPD32
program)
•
This 3333.3300ip.txt config file has the firmware for Dec 3 2008 –
•
The phone will navigate to the TFTP server (as specified in Auto Image Server) and
download the firmware (as specified in Auto Image Name)
•
The phone will reboot and after securing another IP address the warbling tone begins
again (notifying the tester that a config file number should be entered)
•
That is the configuration in which the phones should go out the door. The warbling
tone prompt must be present for installers in the field.
The syntax of the 3333.3300ip.txt file that will upgrade firmware and clear the critical
part of the config file (config ID) is as follows (and can be renamed)
<<VOIP CONFIG FILE>>Version:2.0003
you want to do an update.
<AUTOUPDATE CONFIG MODULE>
Auto Image Server :192.168.10.25
the firmware upgrade
Auto Image Name :21b4V1_7_235_235T20081203121150.z
Firmware name
Auto Image User :
Auto Image Password:
Auto Image Protocol:2
(4) is for HTTP servers
<AUTOUPDATE CONFIG MODULE>
Download Username :user
Download password :pass
Download Server IP :0.0.0.0
Config File Name :
This Config File Name field must be clear at boot-up in order for installers to receive the warbling tone prompt
Config File Key :
Download Protocol :1
Download Mode :0
Download Interval :1
<<END OF FILE>>
Addendum 4 December 2008
Comment:This version number must increment every time
Comment: This is the tftp server that will transfer the config file AND
This Auto Image Protocol (2) indicates TFTP protocol will be used (1) is for FTP and
Example only
This is December 3rd Code
