xStatus Video Output HDMI [1, 3] Resolution Height
Shows the resolution height (in pixels) for the video output HDMI.
Value space of the result returned:
<120..3000>
Example:
xStatus Video Output HDMI 1 Resolution Height
*s Video Output HDMI 1 Resolution Height: 720
** end
xStatus Video Output HDMI [1, 3] Resolution Width
Shows the resolution width (in pixels) for the video output HDMI.
Value space of the result returned:
<176..4000>
Example:
xStatus Video Output HDMI 1 Resolution Width
*s Video Output HDMI 1 Resolution Width: 1280
** end
xStatus Video Output HDMI [1, 3] Resolution RefreshRate
Shows the resolution refresh rate (Hz) for the video output HDMI.
Value space of the result returned:
<1..300>
Example:
xStatus Video Output HDMI 1 Resolution RefreshRate
*s Video Output HDMI 1 Resolution RefreshRate: 60
** end
Codec C90 API Reference Guide TC7.0, JANUARY 2014.
D14641.15
About the API xConfiguration
xStatus Video Output HDMI [1, 3] Connected
xStatus Video Output DVI [n] MonitorRole
209
xCommand
Indicates whether a display is connected to the HDMI video output or not. NOTE: When a display
enters standby mode, the endpoint may not be able to detect it. The connector status will then
return False/Unknown even if the display is physically connected.
True - A display is connected to the video output connector.
False - No display is connected to the video output.
Value space of the result returned:
<True/False>
Example:
xStatus Video Output HDMI Connected
*s Video Output HDMI 1 Connected: False
** end
Describes which video stream is shown on the monitor connected to the video output DVI
connector.
First/Second/Third/Fourth: The role of the monitor in a multi-monitor setup. In a singlemonitor setup,
there is no difference between First, Second, Third and Fourth.
PresentationOnly: Shows presentation video stream if active.
Recorder: Shows all participants, including the local main video. If active, shows also the
presentation.
InternalSetup: Determined by the system, when xConfiguration Video Output HDMI [n] MonitorRole
is set to Auto.
Value space of the result returned:
<First/ Second/ Third/ Fourth/ PresentationOnly/ Recorder/ InternalSetup>
Example:
xStatus Video Output DVI 2 MonitorRole
*s Video Output DVI 2 MonitorRole: First
** end
