xCommand Video PIP ActiveSpeaker Set
Sets position for the active speakers PiP (picture in picture).
Position: Predefined positions.
CenterLeft: The ActiveSpeaker PiP appears on the left side of the screen, in center.
CenterRight: The ActiveSpeaker PiP appears on the right side of the screen, in center.
LowerLeft: The ActiveSpeaker PiP appears in the lower left corner of the screen.
LowerRight: The ActiveSpeaker PiP appears in the lower right corner of the screen.
UpperCenter: The ActiveSpeaker PiP appears on top of the screen, in center.
UpperLeft: The ActiveSpeaker PiP appears in the upper left corner of the screen.
UpperRight: The ActiveSpeaker PiP appears in the upper right corner of the screen.
Requires user role: ADMIN
Parameters:
Position(r): <CenterLeft/CenterRight/LowerLeft/LowerRight/UpperCenter/UpperLeft/UpperRight>
Example:
xCommand Video PIP ActiveSpeaker Set Position: UpperRight
*r ActiveSpeakerPipSetResult (status=OK):
** end
xCommand Video PIP Presentation Set
Sets position for the presentation PiP (picture in picture).
Position: Predefined positions.
CenterLeft: The presentation PiP appears on the left side of the screen, in center.
CenterRight: The presentation PiP appears on the right side of the screen, in center.
LowerLeft: The presentation PiP appears in the lower left corner of the screen.
LowerRight: The presentation PiP appears in the lower right corner of the screen.
UpperCenter: The presentation PiP appears on top of the screen, in center.
UpperLeft: The presentation PiP appears in the upper left corner of the screen.
UpperRight: The presentation PiP appears in the upper right corner of the screen.
Requires user role: ADMIN
Parameters:
Position(r): <CenterLeft/CenterRight/LowerLeft/LowerRight/UpperCenter/UpperLeft/UpperRight>
Example:
xCommand Video PIP Presentation Set Position: LowerLeft
*r PresentationPipSetResult (status=OK):
** end
Codec C90 API Reference Guide TC7.0, JANUARY 2014.
D14641.15
About the API xConfiguration
xCommand Video Selfview Set
137
xCommand xCommand
Sets self-view on/off and specifies its size and position. If the parameter is not specified, current
value is used.
Mode: Selfview on/off
FullscreenMode: Self-view in fullscreen or pip.
PIPPosition: Predefined PIP positions.
FullscreenMode: Choose between displaying the self-view in full screen or not.
PIPPosition: Select the position for the self-view image.
CenterLeft: The self-view PiP appears on the left side of the screen, in center.
CenterRight: The self-view PiP appears on the right side of the screen, in center.
LowerLeft: The self-view PiP appears in the lower left corner of the screen.
LowerRight: The self-view PiP appears in the lower right corner of the screen.
UpperCenter: The self-view PiP appears on top of the screen, in center.
UpperLeft: The self-view PiP appears in the upper left corner of the screen.
UpperRight: The self-view PiP appears in the upper right corner of the screen.
OnMonitorRole: Displays self-view on monitors with this role.
Requires user role: ADMIN
Parameters:
Mode(o): <On/Off>
FullscreenMode(o): <On/Off>
PIPPosition(o): <CenterLeft/CenterRight/LowerLeft/LowerRight/UpperCenter/UpperLeft/
UpperRight>
OnMonitorRole(o): <First/Fourth/Second/Third>
Example:
Example 1
xCommand Video Selfview Set Mode: On FullscreenMode: Off PIPPosition:
CenterLeft OnMonitorRole: First
OK
*r SelfviewSetResult (status=OK):
** end
Example 2
xCommand Video Selfview Set FullscreenMode: On OnMonitorRole: Second
OK
*r SelfviewSetResult (status=OK):
** end
