Specifications - MULTIQUIP DCA180SSJ Specifications

Specifications

Generator Specifications
Design
No. of Poles
Excitation
Standby Output
Prime Output
Generator RPM
Voltage - 3 phase 208, 220, 240, 415, 440, 480V Reconnectable
Voltage - single phase 120, 127, 139, 240, 254, 277V Adjustable
Armature Connection
Voltage Regulation
(No load to full load)
Power Factor
Frequency
Frequency Regulation:
No Load to Full Load
Frequency Regulation: ±0.25% of mean value for constant loads
Steady State
Insulation
Sound Level dB(A)
Full load at 23 feet
Engine Specifications
Make/Model
Emissions
Starting System
Design
Displacement
No. cylinders
Bore x Stroke (mm)
Gross Engine Power Output
BMEP
Piston Speed
Compression Ratio
Engine Speed
Overspeed Limit
Oil capacity gallons (liters)
Battery
Fuel System
Recommended Fuel
Maximum Fuel Flow (per hour)
Maximum Inlet Restriction (Hg)
Fuel Tank Capacity
Fuel Consumption
full load
75% load
50% load
25% load
DCA180SSJU Rev 4
Revolving field, Self-ventilated,
Drip-proof, Single bearing
4-pole
Brushless with AVR
158 KW (198 KVA)
144 KW (180 KVA)
1800
Star with neutral
±0.5%
0.8
60 Hz
Isochronous under varying loads from
no load to 100% rated load
from no load to full load
Class F
72
John Deere / 6068HF485
EPA Tier 3 Certified
Electric
4-cycle, Watercooled, Direct injection,
Turbocharged, Air to air intercooled
6800 cc
6
106 x 127
315 hp (235 kW)
304 psi (2094 kPa)
1134 ft/min (5.76 m/s)
17 : 1
1800 rpm
2100 rpm
8.19 (31.0)
12V 128 Ah
ASTM-D975-No.1 or No. 2-D
22.7 gal. (85.9 L)
5.9 in. (150 mm)
100 gal. (380 L)
gph lph
11.4 43.0
9.0 34.1
6.6 25.1
4.3 16.2
DCA180SSJ
WhisperWatt
Cooling System
Fan Load
Coolant Capacity (with radiator)
Coolant Flow Rate
Heat Rejection to Coolant
Heat Radiated to Room
Maximum Coolant Friction Head
Maximum Coolant Static Head
Ambient Temperature Rating
Air
Combustion Air
Maximum Air Cleaner Restriction
Alternator Cooling Air
Radiator Cooling Air
Exhaust System
Gas Flow (full load)
Gas Temperature
Maximum Back Pressure
Amperage
Rated Voltage
1Ø 120 Volt
1Ø 240 Volt
3Ø 240 Volt
3Ø 480 Volt
Main Line Circuit Breaker Rating
Over Current Relay Trip Set Point
Warranty*
John Deere Engine
12 months from date of purchase and unlimited hours or 24 months
from date of purchase with 2000 hours (whichever ocurs first).
*Refer to the express written, Engine warranty sheet for additional coverage
information.
Generator
24 months from date of purchase or 2000 hours (whichever occurs
first).
*Refer to the express written, one-year limited warranty sheet for additional
information.
Trailer
12 months excluding normal wear items.
Generator is not intended for use in enclosed areas or where free flow of air is restricted.
Backfeed to a utility system can cause electrocution and/or property damage. Do not
connect to any building's electrical system except through an approved device.
Specifications are subject to change without notice.
TM
Generator
21.5 hp (16 kW)
6.3 gal. (24 L)
70 gal. (265 L)
5404 Btu (5.7 MJ)
3264 Btu (3.44 MJ)
2 psi (13.8 kPa)
21 ft. (6.4)
104°F (40°C)
619 cfm (17.5 m
25.0 in H 2 0 (6.25 kPa)
1459 cfm (41.3 m
8120 cfm (230 m
1371 cfm (38.8 m3/min)
905°F (485°C)
2
40.0 in. H 0 (10 kPa)
Maximum Amps
400 Amps (4 wire)
200 Amps (4 wire)
433 Amps
216 Amps
500 Amps
216 Amps
3
/min)
3
/min)
3
/min)
