Shut-Down/Long Term Storage - MULTIQUIP GDP-5H Operation And Parts Manual

Stopping the Engine
1. Place both the 60 and180 Hz circuit breakers (Figure
25) in the OFF position.
Figure 25. 60 and 180 Hz Breakers (Off)
2. Place the idle control switch (Figure 26) in the OFF
position.
Figure 26. Idle Control Switch (Off)
3. Let the engine run at idle with no load for 2-3 minutes.
4. To shut-down the engine, place the generator ON/OFF
switch (Figure 27) in the OFF position
Figure 27. Generator On/Off Switch (Off)
GDP-5H A.C. GENERATOR — PARTS & OPERATION MANUAL — REV. #2 (10/05/05) — PAGE 29
GDP-5H — SHUTDOWN/ LONG TERM STORAGE
5. Place the engine fuel valve lever (Figure 28) to the "OFF"
position. "
Figure 28. Engine Fuel Valve Lever (OFF Position)
6. Remove the load from the generator.
Generator Storage
For storage of the generating set for over 30 days, the
following is required:
■ Drain the fuel tank completely, or add STA-BIL to the fuel.
■ Run the engine until the gasoline in the carburetor is
completely consumed.
■ Completely drain the oil from the crankcase and refill with
fresh oil.
■ Remove the spark plug, pour 2 or 3 cc of SAE 30 oil into the
cylinder and crank slowly to distribute the oil.
■ Slowly rotate the engine a few times with the starter rope and
install a new spark plug.
■ Pull out the starter rope slowly and stop at the compression
point.
■ Clean all external parts of the generating set with a cloth.
■ Cover the generating set and store in a clean, dry place.
