Connecting a Footswitch

(Optional)
The Punch In connector on the Command|8
back panel supports footswitch control of Track-
Punch and QuickPunch audio punch-in and
punch-out recording features. Both continuous
on/continuous off and instantaneous on/off
pedals with a 1/4-inch TRS connector are sup-
ported.
To connect a footswitch:
Connect the footswitch jack to the Punch In
connector.
Connecting MIDI Devices to
Command|8
Command|8 provides 16 channels of MIDI in-
put and 32 channels of MIDI output through
the MIDI IN 1, MIDI OUT 1, and MIDI OUT 2
connectors on the back panel. The connectors
accept standard 5-pin MIDI cables.
Command|8 driver software, installed when you
install Pro Tools (or standalone) software, is re-
quired for MIDI communication to function.
These drivers are recognized by MIDI Studio
Setup (Windows), and by Audio MIDI Setup
(Mac).
To connect MIDI devices to Command|8 for
Pro Tools:
Using standard 5-pin MIDI cables, connect the
1
MIDI Out port of a MIDI keyboard or other MIDI
device to the MIDI In 1 port of your Com-
mand|8, and connect the MIDI In port of your
MIDI device or controller to the MIDI Out 1 port
of your Command|8.
12 Command|8 Guide
Connect MIDI Out 2 of Command|8 to the
2
MIDI In port of an additional MIDI device (such
as a sound module).
To monitor or record the audio output of your
3
MIDI devices within Pro Tools, connect the au-
dio outputs of your devices to available audio in-
puts on your Pro Tools audio interface.
USB MIDI Communication and
Command|8 Operating Modes
When connected to Pro Tools through USB,
Command|8 is recognized as a MIDI Control
Surface and MIDI interface (Command|8 MIDI
connectors are available as MIDI In and Out
ports).
Configuring MIDI
Communication with
Command|8
After connecting Command|8 and installing its
software, configure your MIDI studio to com-
municate with Command|8.
Configuring Audio MIDI Setup
(Mac Only)
On Mac systems, use Audio MIDI Setup to con-
figure MIDI communication with Command|8.
To update AMS for Command|8:
Launch Audio MIDI Setup (located in Applica-
1
tions/Utilities) or choose Setup > MIDI > MIDI
Studio in Pro Tools.
Make sure that Command|8 is recognized, is
2
online, and that its three ports are available in
AMS.
