Vegas Mode

Vegas mode rapidly turns each switch LED,
meter segment, and 7-segment display LED on
and off in a randomized fashion. The faders are
also run in sine wave mode.
To enter Vegas mode:
Press UTILITY > Test > LED > Vgas (Vegas).
1
You can change the rate at which this LED up-
2
dating occurs by rotating either a channel en-
coder or the SCRUB/SHUTTLE wheel. Turning
an encoder or the scrub wheel to the left de-
creases this rate while turning to the right in-
creases the speed.
When finished, press EXIT.
3

Switch Test Mode

Switch test mode allows you to test each switch
on the control surface individually.
To enter Switch test mode:
Press UTILITY > Test > LED > Swch (switch).
1
Press any switch on Control|24. When
2
pressed, the switch LED will light as long as it is
held and the channel scribble strips will show
the location information for the switch.
When finished, press EXIT.
3

Test Modes for LED Colors

Red LED mode, Yellow LED mode, and Green
LED mode, are used to check for proper lighting
of all LEDs of the specified color on the control
surface by illuminating only LEDs of that color.
For example, when Red LED Test mode is
engaged:
• The encoder switch LED located below the
scribble strip which shows "Red" will light
solid indicating that this is the chosen test
mode.
• All other LED test menu items shown on the
scribble strips as well as their associated flash-
ing encoder switch LEDs, will remain visible
in this test mode. This allows you to select an-
other LED test mode without the need to first
"Exit" this mode.
• Press the flashing encoder switch located be-
low the scribble strip showing another test
mode to simultaneously disengage the red
LED test mode and enter the newly selected
mode. The encoder switch LED for the new
choice will light solid while the other choices
flash.
• When finished, press EXIT.
The test modes for Yellow and Green LEDs
function the same way.
Appendix B: Utility Functions
133
