Summary of Contents for Da-Lite Large Cosmopolitan Electrol
- Page 1 The Da-Lite Difference. Instruction Book for DA-LITE SCREEN COMPANY LLC 3100 North Detroit Street LARGE CoSMoPoLITAN® ELECTRoL® Post Office Box 137 Warsaw, IN 46581-0137 USA P 800-622-3737 / 574-267-8101 F 877-325-4832 / 574-267-7804 www.da-lite.com e-mail: info@da-lite.com...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS when using your video equipment, basic safety precautions should always be followed, including the following: 1. Read and understand all instructions before using. 2. To reduce the risk of electric shock, do not disassemble this appliance. Contact an authorized service dealer when repair work is required.
- Page 3 This swiTCh CAn noT BE usEd wiTh LvC. 240 VOLT WIRING DIAGRAM FOR STANDARD WALL SWITCH: da-Lite offers two styles of 240 volt wall switches for standard operation. Please see wiring diagram in wall switch boxes included with screen.
- Page 4 SCREEN AdjUSTMENT FOR SCREENS WITHOUT A BUILT-IN LOW VOLTAGE CONTROL screen travel is stopped automatically in the down and up positions by the limit switches that are preset at the factory. no further adjustment is necessary. if you need to make minor stop position adjustments see the appropriate step below. SETTING THE DOWN LIMIT POSITION NOTE: One turn of the limit screw equals approximately 2"...
- Page 5 LARGE COSMOPOLITAN ® ELECTROL ® INSTALLATION FOR 120V SCREENS WITH A BUILT-IN LOW VOLTAGE CONTROL RJ-14 PIN-OUTS RJ-22 PIN-OUTS 120V WIRING DIAGRAM (TAB IS FACING UP) (TAB IS FACING UP) WITH OPTIONAL BUILT-IN +12V BLUE BUS (RP DATA) WHITE BUS (RP DATA) YELLOW LOW VOLTAGE CONTROL RQ DATA...
- Page 6 LARGE COSMOPOLITAN ® ELECTROL ® INSTALLATION FOR 240V SCREENS WITH A BUILT-IN LOW VOLTAGE CONTROL CONNECT SUPPLIED RJ9 CABLE TO SPLITTER AND 240V WIRING DIAGRAM SWITCH, OR USE 4 CABLE CONDUCTOR WITH OPTIONAL BUILT-IN OPTIONAL IR AND RF TO CONNECT TO LOW-VOLTAGE WALL SWITCH SCREW TERMINALS.
- Page 7 Visit www.da -lite.com/products/product_videos.php to find installation and troubleshooting videos and tutorials. You will also find a link to Live Chat for interactive support and you can contact us by email at info@da-lite.com or by phone at (800) 622-3737 or (574) 267-8101 with any troubleshooting questions. SYMPTOM...
- Page 8 EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. in the event that there is a defect in materials or workmanship of a da-Lite product, you may contact our sales Partners at Po Box 137, warsaw, in 46581-0137, (574) 267-8101, (800) 622-3737.
