MULTI VISION IMAGER INSTALLATION
120V WIRING DIAGRAM
LED
UP LIMIT
TACTILE
BUTTON
U P
S T O
P
D O W
N
DOWN LIMIT
TACTILE
BUTTON
FRONT OF
BACK OF
WALL SWITCH
WALL SWITCH
3-conductor 20-24 gauge wire can be used in place of
the supplied RJ-14 cable to connect the wall switch.
Connect the BUS terminals on the wall switch to the
corresponding BUS terminals on the splitter board.
IMPORTANT NOTE:
The wall switch is REQUIRED to make any limit switch
adjustments, EVEN if a third party control system is
used. Therefore, it is advised to wire the switch or
provide a 3-conductor connection that is accessible.
240V WIRING DIAGRAM
BLUE
(COMMON)
BROWN
(HOT)
240VAC 50HZ
GREEN
GROUND–MUST BE
CONNECTED TO
BUILDING GROUND
ILT RJ9 PIN-OUTS
(TAB IS FACING UP)
IR or UP
BLACK
GND COMMON
RED
+5V
GREEN
DN or DATA
WHITE
RJ-22
INPUTS
RJ-22
JACK
BUS
MOTOR
GREEN
GROUND TO CASE
IMPORTANT NOTE: The wall switch is REQUIRED to make any limit
RJ-14 PIN-OUTS
(TAB IS FACING UP)
BUS (RP DATA)
WHITE
RQ DATA
GREEN
+5V
RED
GND
BLACK
RJ-22
JACK
Supplied RJ-14 cable
RJ-22
OUTPUT
UP
DOWN
DRY CONTACTS
COMMON
BUS
BUS
5V
RJ-45
RECEPTACLE
RJ-45 JACK
POWER WIRE
BLACK (HOT)
WHITE (COMMON)
POWER INPUT 120VAC / 60HZ
OPTIONAL IR AND RF
REMOTE CONTROL
RJ9
SPLITTER
DRY CONTACTS
switch adjustments, EVEN if a third party control
system is used. Therefore, it is advised to wire
the switch or provide a 4-conductor connection
that is accessible.
5
RJ-22 PIN-OUTS
(TAB IS FACING UP)
+12V
BUS (RP DATA)
RQ DATA
+5V
GND
RQ CLOCK
Standard RJ-22 can be used in place of RJ-14
RJ-45 PIN-OUTS
(TAB IS FACING UP)
MANUAL 2
+12V
BUS (RP DATA)
RQ DATA
+5V
GND
RQ CLOCK
DATA
MANUAL 1
CABLE
GREEN (GROUND)
GROUND–MUST BE
CONNECTED TO
FIGURE 5
BUILDING GROUND
LOW-VOLTAGE WALL SWITCH
UP
RJ9
STOP
DOWN
FRONT
FIGURE 6
BLUE
YELLOW
GREEN
RED
BLACK
WHITE
BROWN
BLUE
YELLOW
GREEN
RED
BLACK
ORANGE
PURPLE
UP DN
GND +5V
3-POSITION
RJ9
SWITCH
BACK
