Control Panel Assembly - MULTIQUIP DA7000SS Operation And Parts Manual

NO. PART NO.
1 A5225000303
1 A5511302402
2 0021805020
3 0601800258
4 0207003000
5 0601807456
6 4341817004
7 0021004016
8 0601830771
9 1628663602
9A 3741055150
10 0601810523
10A 0601810830
11 0601800682
12 0027403512
12A 0030003500
13 0601811034
14 0601812529
15 0601811031
16 0601812597
17 0021004010
17A 0030004000
18 0601806420
19 0027103005
20 0601815109
DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 67
PART NAME
CONTROL PANEL
CONTROL PANEL .............................................1................DA7000SSA
MACHINE SCREW
AC VOLTMETER, 120/240
HEX NUT
CIRCUIT BREAKER, KM52 265V 25A
BRACKET CIRCUIT BREAKER
MACHINE SCREW
IDLE CONTROL SWITCH
STARTER SWITCH ...........................................1................REPLACES 0602100077
IGNITION, KEY
INDICATOR ASSY.
BULB
HOUR METER 820114
MACHINE SCREW
HEX NUT
RECEPTACLE CS6369 125 250V 50A ..............1................REPLACES 0601812566
RECEPTACLE, L14- 30R 125V 30A
RECEPTACLE, L5-30R 125V 30A .....................1................REPLACES 0601811035
RECEPTACLE, 5-20R 120V 20A ......................1................REPLACES 0601812598
MACHINE SCREW
HEX NUT ...........................................................8................REPLACES 0207004000
CIRCUIT PROTECTOR, AC 250V 20A
MACHINE SCREW
GROUND TERMINAL
CONTROL PANEL ASSY.
QTY. REMARKS
1
4
1
2
1
1
2
1
1
4
1
2
2
1
8
1
2
1
