KUBOTA Z482-EB/E2B/E3B ENG. — PISTON AND CRANKSHAFT ASSY.
PISTON AND CRANKSHAFT ASSY.
NO. PART NO.
010 1685121112
010 1685121114
010 1685121900
010 1685121903
020 1685321050
020 1685321090
030 1685121310
040 1526121330
050 1685122010
050 1685122015
060% 1685121980
060+ 1685121982
070%+ 1685122140
080%+ 1685122320
080 1586122970
080 1586122980
090 1685323030
100# 0771503207
110# 1921523280
120 1584124110
130 0571200515
140 1586123470
140 1586123910
140 1586123920
150 1686123480
150 1569423930
150 1569423940
160 1686123490
160 1586123860
160 1586123870
170 1526123530
170 1526123950
170 1526123960
180 1526123540
180 1526123970
180 1526123980
190 1584123250
200 1588123310
210 0481416220
DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 111
PART NAME
PISTON STD ...................................................2................Z482-EB AND Z482-E2B
PISTON STD ...................................................2................Z482-E3B
PISTON +0.25MM ..............................................2................Z482-EB AND Z482-E2B
PISTON +0.25MM ..............................................2................Z482-E3B
ASSY. PISTON RING STD
ASSY. PISTON RING +0.25MM
PIN, PISTON
AIR CLIP, PISTON PIN
CONNECTING ROD ASSY., Z482-EB...............2................INCLUDES ITEMS W/%
CONN. ROD ASSY. Z482-E2B/E3B ...................2................INCLUDES ITEMS W/+
BUSH, PISTON PIN ...........................................2................Z482-EB
BUSH, PISTON PIN ...........................................2................Z482-E2B AND Z482-E3B
BOLT, CONNECTING ROD
METAL, CRANKPIN M STD SET
METAL, CRANKPIN -0.20MM SET
METAL, CRANKPIN -0.40MM SET
CRANKSHAFT ASSY. ........................................1................INCLUDES ITEMS W/#
BALL
SLEEVE, CRANKSHAFT
GEAR, CRANK
KEY, FEATHER
METAL, CRANKSHAFT STD
METAL, CRANKSHAFT -0.20MM
METAL, CRANKSHAFT -0.40MM
METAL, CRANKSHAFT M STD SET
METAL, CRANKSHAFT -0.20MMSET
METAL, CRANKSHAFT -0.40MMSET
METAL, CRANKSHAFT STD SET
METAL, CRANKSHAFT -0.20MM SET
METAL, CRANKSHAFT -0.40MM SET
METAL, SIDE STD
METAL, SIDE +0.20MM
METAL, SIDE +0.40MM
METAL, SIDE STD
METAL, SIDE +0.20MM
METAL, SIDE +0.40MM
COLLAR, CRANKSHAFT
SLINGER, OIL
O-RING
QTY. REMARKS
2
2
2
4
4
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
1
1
1
