Control Panel Assembly - MULTIQUIP DAC7000SS Operation And Parts Manual

NO. PART NO.
1 A5225001503
1 A5511302802
2 0021805020
3 0601806819
4 0207003000
5 0601807465
6 4341817004
7 0021004016
8 0601830771
9 1628663602
9A 3741055150
10 0601810523
10A 0601810830
11 0601800682
12 0027403012
12A 0030003000
13 0601812565
14 0601812529
15 0601811031
16 0601812590
17 0021004010
17A 0030004000
18 0601806428
19 0027103006
20 0601815147
DAC7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #0 (02/15/16) — PAGE 67
PART NAME
CONTROL PANEL
CONTROL PANEL .............................................1................DAC7000SSA
MACHINE SCREW
AC VOLTMETER, 120/240V
HEX NUT
CIRCUIT BREAKER, 265V 25A
BRACKET CIRCUIT BREAKER ........................1................DAC7000SS
MACHINE SCREW
IDLE CONTROL SWITCH
STARTER SWITCH ...........................................1................REPLACES P/N 0602100077
IGNITION, KEY
INDICATOR ASSY.
BULB
HOUR METER
MACHINE SCREW
HEX NUT
RECEPTACLE CS6369 125 250V 50A
RECEPTACLE, L14- 30R 125V 30A
RECEPTACLE, L5-30R 125V 30A .....................1................REPLACES P/N 0601811035
RECEPTACLE, 5-15R 120V 15A
MACHINE SCREW
HEX NUT ...........................................................8................REPLACES P/N 0207004000
CIRCUIT PROTECTOR, AC 250V 15A
MACHINE SCREW
GROUND TERMINAL
CONTROL PANEL ASSY.
QTY. REMARKS
1
4
1
2
1
2
1
1
1
4
1
2
2
1
1
1
8
1
2
1
