2. If there is a cardboard tube (not shown) on the
front the Frame (54), remove and discard the
attachment screw and the cardboard tube.
Set a sturdy piece of packing material under the
front of the Frame (54). Have a second person
hold the Frame to prevent it from tipping
while you complete this step.
Attach the Front Stabilizer (37) to the Frame (54)
with two M8 x 82mm Screws (53), two M8 Split
Washers (8), and two M8 Washers (71).
Remove the packing material.
3. Orient the Right Pedal (76) as shown.
Attach the Right Pedal (76) to the Right Pedal
Arm (75) with two M10 x 45mm Bolts (39), two
M10 Washers (10), and two M10 Locknuts (32).
Attach the Left Pedal (not shown) to the Left
Pedal Arm (not shown) in the same way.
2
54
3
39
76
75
7
53
37
8
71
10
32
