Model No. WLEL2005.0
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-866-699-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and
instructions in this manual
before using this equipment.
Keep this manual for future
reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo Momentum 745 Elliptical
Summary of Contents for Weslo Momentum 745 Elliptical
- Page 1 Mon.–Fri., 6 a.m.–6 p.m. MST ON THE WEB: www.wesloservice.com CAUTION Visit our website at Read all precautions and instructions in this manual www.weslo.com before using this equipment. Keep this manual for future new products, prizes, reference. fitness tips, and much more!
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . -
Page 3: Before You Begin
BEFORE YOU BEGIN Congratulations for selecting the new WESLO ® product model number and serial number before call- MOMENTUM 745 low-impact elliptical exerciser. The ing. The model number is WLEL2005.0. The serial MOMENTUM 745 is an incredibly smooth exerciser number can be found on a decal attached to the ellip- that moves your feet in a natural elliptical path, mini- tical exerciser (see the front cover of this manual). -
Page 4: Assembly
ASSEMBLY To hire an authorized service technician to assemble the elliptical exerciser, call toll-free 1-800-445-2480. Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires a phillips screwdriver , two adjustable wrenches , and a rubber... - Page 5 1. Attach the Rear Stabilizer (4) to the Frame (1) with two M10 x 75mm Carriage Bolts (34) and two M10 Nylon Locknuts (29). 2. Hold the Lower Cable (15) and the Lower Wire Harness (65) in the indicated slot in the Frame (1), and insert the Front Stabilizer (3) into the Frame.
- Page 6 5. While another person holds the Console (5) near the Console Bracket (26), insert the console cable into Console the Console Bracket and down through the Upright Cable (2). Next, connect the console wire to the Upper Wire Ground Harness (55). Then, connect the ground wire to the Wire Console Bracket with an M4 x 16mm Screw (66).
- Page 7 7. Identify the Left Handlebar (9), which is marked with a sticker. Insert the Left Handlebar (9) into one of the Handlebar Legs (39). Make sure that the Left Handlebar is oriented as shown. Attach the Left Handlebar with two M8 x 45mm Button Bolts (50) and Hexagonal two M8 Nylon Locknuts (46).
-
Page 8: How To Use The Elliptical Exerciser
10. Apply a thin film of grease to the shaft of a Bolt Set (27) and to the axle on the left Crank Arm (36). Slide a Pedal Spacer (64) and the left Pedal Arm (14) onto the axle on the left Crank Arm (36). Attach the Grease Pedal Arm with a Pedal Arm Axle Cap (16). - Page 9 HOW TO OPERATE THE CONSOLE FEATURES OF THE CONSOLE Pulse—This mode displays your heart rate when you use the pulse sensor. The easy-to-use console is designed to help you get the most from your workouts. As you exercise, the Speed—This mode displays your pedaling speed. console will display the following modes: Scan—When this mode is selected, the upper section Time—This mode displays the elapsed time (or the...
- Page 10 HOW TO USE THE MANUAL MODE To cancel the scan mode, Note: If there is a sheet of clear plastic on the console, press the Mode peel off the plastic. button. The mode bar below the word SCAN Turn on the console. will disappear.
- Page 11 HOW TO USE A PACE PROGRAM As the target pace indicator changes in height during the program, adjust your pedaling pace so that both indicators are the same height. If your Turn on the console. pedaling pace is slower than the current target pace setting, an arrow will appear next to the See step 1 on page 10.
-
Page 12: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the elliptical Remove the indicated Screws (62) from the Right exerciser regularly. Replace any worn parts immedi- Side Shield (7). Remove the indicated Screws (66) ately. from both Side Shields (6, 7). Lift the Side Shields off the elliptical exerciser. -
Page 13: Conditioning Guidelines
CONDITIONING GUIDELINES Fat Burning WARNING: To burn fat effectively, you must exercise at a relative- ly low intensity level for a sustained period of time. Before beginning this or any exercise pro- During the first few minutes of exercise, your body gram, consult your physician. -
Page 14: Part List
PART LIST—Model No. WLEL2005.0 R0805A Key No. Qty. Description Key No. Qty. Description Frame Pulley Upright Pivot Axle Front Stabilizer Handlebar Leg Rear Stabilizer Crank Bearing Console Flywheel Left Side Shield Flywheel Bearing Right Side Shield Magnet Pedal Disk Flywheel Axle Left Handlebar M4 x 64mm Screw Right Handlebar... -
Page 15: Exploded Drawing
EXPLODED DRAWING—Model No. WLEL2005.0 R0805A... -
Page 16: How To Order Replacement Parts
• the MODEL NUMBER of the product (WLEL2005.0) • the NAME of the product (WESLO MOMENTUM 745 elliptical exerciser) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER and DESCRIPTION of the part(s) (see page 14) WESLO is a registered trademark of ICON IP, Inc.
