Model No. WLEL28021
Serial No.
Serial Number
Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE. The
technicians on our customer hot
line will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manu-
al for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo Momentum 750 Elliptical
Summary of Contents for Weslo Momentum 750 Elliptical
- Page 1 1-800-999-3756 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.weslo.com this equipment. Keep this manu- new products, prizes, al for future reference. fitness tips, and much more!
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. .Back Cover WESLO is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the elliptical crosstrainer. 1. Read all instructions in this manual before 7. Wear appropriate exercise clothing when using the elliptical crosstrainer. Use the using the elliptical crosstrainer. -
Page 4: Before You Begin
Congratulations for selecting the new WESLO Customer Service Department toll-free at 1-800-999- ® MOMENTUM 750 elliptical crosstrainer. The MOMEN- 3756, Monday through Friday, 6 a.m. until 6 p.m. TUM 750 elliptical crosstrainer is an incredibly smooth Mountain Time (excluding holidays). To help us assist... -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Place all parts of the elliptical crosstrainer in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included allen wrenches, assembly requires a Phillips screwdriver , an adjustable wrench , and a rubber mallet... - Page 6 2. While another person lifts the back of the Frame (1), attach the Rear Stabilizer (28) to the Frame with two M10 x 75mm Carriage Bolts (34) and two M10 Nylon Locknuts (33). 3. The Console (23) requires three “AA” batteries (not Batteries included);...
- Page 7 6. Identify the Left Handlebar (6), which is marked with a sticker. Insert the Left Handlebar into one of the Handlebar Arms (5); make sure that the Handlebar Arm is turned so the hexagonal holes are on the indicated side. Attach the Left Handlebar to the Handlebar Arm with two M8 x 38mm Button Bolts (50) and two M8 Nylon Locknuts (38).
- Page 8 8. Apply a small amount of grease to the axle on the left Disc Crossbar (16). Slide the Left Pedal Arm (11) onto the axle. Slide an M10 Washer (35) onto an M10 x 25mm Patch Screw (22), and tighten the Patch Screw into the axle.
-
Page 9: How To Use The Elliptical Crosstrainer
HOW TO USE THE ELLIPTICAL CROSSTRAINER HOW TO EXERCISE ON THE ELLIPTICAL To dismount the elliptical crosstrainer, wait until the CROSSTRAINER pedals come to a complete stop. Note: The elliptical crosstrainer does not have a free wheel; the ped- als will continue to move until the flywheel stops. To mount the elliptical crosstrainer, hold the handlebars and step onto the pedal that is in the lowest position. - Page 10 FEATURES OF THE CONSOLE 2. Select one of the modes: The easy-to-use console features five modes that pro- Scan mode— vide instant exercise feedback during your workouts. Mode Indicators When the power The modes are described below. is turned on, the scan mode will be selected automati- cally.
-
Page 11: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical crosstrainer See the drawing below and locate the Reed Switch regularly. Replace any worn parts immediately. (53). Loosen, but do not remove, the indicated M4 x 16mm Screw (42). Slide the Reed Switch slightly To clean the elliptical crosstrainer, use a damp cloth toward or away from the Magnet (58) on the flywheel. -
Page 12: To Adjust The Resistance Strap
HOW TO ADJUST THE RESISTANCE STRAP If the resistance knob is turned to the highest setting and there is not enough pedaling resistance, the resistance strap can be adjusted. To adjust the resis- tance strap, first remove the left side shield (see HOW TO ADJUST THE REED SWITCH on page 11). -
Page 13: Conditioning Guidelines
CONDITIONING GUIDELINES The following guidelines will help you to plan your Aerobic Exercise exercise program. Remember that proper nutrition and adequate rest are essential for successful results. If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.” Aerobic exer- cise is activity that requires large amounts of oxygen for prolonged periods of time. -
Page 14: Part List
PART LIST—Model No. WLEL28021 R1103A Key No. Qty. Description Key No. Qty. Description Frame M10 x 75mm Carriage Bolt Upright M10 Washer Left Side Shield M6 x 48mm Flat Head Screw Right Side Shield Pedal Arm Bushing Handlebar Arm M8 Nylon Locknut Left Handlebar M10 Washer Idler Assembly... -
Page 15: Exploded Drawing
EXPLODED DRAWING—Model No. WLEL28021 R1103A 51 15... -
Page 16: How To Order Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: • The MODEL NUMBER of the product (WLEL28021) • The NAME of the product (WESLO ® MOMENTUM 750 elliptical crosstrainer) •...
