I M
NSTALLING THE
Caution: Caution: To avoid possible electrical shock, be sure electricity
is turned off at the main power box before wiring. All wiring
must be in accordance with National and Local Electrical
Codes and the ceiling fan must be grounded as a precaution
against possible electric shock.
IMPORTANT NOTE: THIS CEILING FAN EXCEEDS THE IMPORTANT NOTE:
MAXIMUM WEIGHT (35 LBS) SPECIFIED BY UL FOR
HANGING FROM A STANDARD CEILING FAN RATED
OUTLET BOX. SPECIAL REINFORCEMENT TO THE
CEILING IS REQUIRED FOR INSTALLATION!
CAUTION: Wood screws must go through the outlet box and CAUTION:
directly into the building joist or into added cross support.
(Fig. 1)
Step 1. Remove the two knock-outs from the outlet box to
expose the joist. If the outlet box does not have knock-outs,
you will need to drill the holes. (Fig. 1)
Step 2. Secure the mounting bracket directly to the joist from
the building via the knock out holes from the outlet box.
Secure the mounting bracket with the wood screws and lock-
washers provided with the fan. (Fig. 1)
Step 3. Secure the hanger bracket to mounting bracket
using the two hex nuts and washers provided, make sure
nuts are securely tighten. (Fig. 2)
WARNING: Do not over-tighten the hex nut on the heavy WARNING:
duty hanging plate - properly tighten it until it is secured.
Over-tightening the hex nut will result in the breakage of
the bolt.
B
OUNTING RACKET AND
H B
ANGING RACKET
Knock out
Fig. 1
Hanger
bracket
Fig. 1
5
Outlet
box
Mounting
bracket
Lock washers
Flat washers
Wood screws
Mounting
bracket
Flat
washers
Spring
washers
Hex nuts
