Regency Ceiling Fans Regulator Owner's Manual page 11

I
NSTALLING THE
NOTE: Be sure the power is off before installing. NOTE: Be sure the power is off before installing.
1. Loosen the 3 side screws on detachable mounting plate halfway.
2. If installing light kit, carefully remove light kit cover in bottom of switch housing. Attach the light kit to the switch
housing per instructions supplied with light kit. (Follow the instructions included with the kit.)
3. Connect the plug and receptacle and make sure side buckle snaps in place.
4. Attach the switch housing to the mounting plate.
5. Align the side screws with keyhole slots on edge of switch housing and tighten the side screws.
6. Turn the power on. Your Regency Ceiling Fan is now ready to enjoy!
R S
EMOVABLE WITCH
Side Screw (x3)
Light Wires
Keyhole Slot (x3)
Optional Light Kit
connects to bottom
of Switch Housing
H
OUSING
Detachable Switch Housing
Mounting Hub
Switch Housing
10
