I
NSTALLATION OF
M H
OUNTING UB
1. Remove one of the three screws on the mounting hub located on the fan motor.
2. Loosen the other two screws.
3. Install detachable switch housing mounting hub to mounting hub.
4. Pass the 2 light wires through the center hole of the detachable switch housing mounting hub.
5. Line up the two slotted holes with the two loose screws on the mounting hub located on fan motor.
6. Re-install the third screw removed and tighten all three.
D S
ETACHABLE WITCH
Mounting Hub
(bottom of motor)
Light Wires
H
OUSING
Detachable Switch Housing
Mounting Hub
Screws
