3.23 The SystemView Menu

The SystemView Menu Overview
The SystemView menu is provided so that users may quickly view global
software and hardware settings.
e
About DVMR menu: This menu provides information such
as model designation, serial number, software version, software
date, boot code version hard disk size, IP address, and
hardware address (MAC).
View Screens 1 through 8: These menus provide an overview of the units current operating
parameters and the menu settings selected by the user or installer. Each View Screen is described in
the following tables.
The View Screens
View Screen 1
Alarm Input
Enable/Disable: 1 = Enabled, 0 = Disabled
Normally Open or Normally Closed: 0 = Open, C = Closed
Macro: Macro number if activated
Alarm Action
Freeze: 1 = Freeze, 0 = No Freeze
Cameras: Primary camera in alarm and three associated cameras
Relay: 1, 2, 1+2, or None
View Screen 2
Camera
Enable/Disable: 1 = Enabled, 0 = Disabled
Signal Gain: AGC setting from 1 through 10
Covert Camera: Yes or No
Camera Title
Videoloss Action
Relay 1: 1 = Enabled, 0 = Disabled
Relay 2: 1 = Enabled, 0 = Disabled
Buzzer: 1 = Enabled, 0 = Disabled
0150-0193C 56
About DVMR
View Screen 1
View Screen 2
View Screen 3
View Screen 4
View Screen 5
View Screen 6
View Screen 7
View Screen 8
Model: DVMRe-16CT
Serial Number: D406-T72-210001
Software Version: VER 4.08
Software Date: Oct 15 16:40:18 2002
Boot Code Version: VER 1.03
Disk Size: 163.93 GB
IP Address: 3.18.173.10
Hardware Address: BA-BE-C6-7E-FA-CE
