Conditional Indicators
Condition
Alarm
Autolist™ Program
mode
Freeze
Macro Record mode
Motion Detection
Videoloss
Zoom
Status Display Box
A Status Display Box can be viewed by pressing the Camera Number button twice. Status Indicators
include:
On Live Fullscreen:
Archive Status: Not Connected, Not Ready, Ready, Ejecting, Play, and timeleft. Timeleft
indicates the amount of time before the archive medium is full (Only available if the unit has
Background Archiving turned On).
Network: Displays all current Network connections. Normal connection is displayed as ip.ip or ---
if there is no connection. Live connections are displayed as E1: ip.ip, E2: ip.ip, etc. (where ip.ip
represents the last 2 bytes of the IP Address). POTS connection is displayed as IP 1.1.
On Playback Fullscreen:
All the above, including Image Quality Setting: High, Medium, Standard.
ATM/POS Text Display
Pressing the Camera Number a third time displays an ATM/POS text display. This feature can be
used during live viewing mode to verify that the DVMRe Triplex is receiving ATM/POS text, or in
Playback mode to review recorded text and video.
0150-0193C
Full Screen Indicator
ALM
PGM
FRZ
F followed by macro number
M
VDL
ZOOM
24
Multiscreen Indicator
A in cameo of camera in alarm
PGM
(Asterisk) in frozen cameo
*
F followed by macro number
M in cameo w/ motion detection
V in cameo with videoloss
ZOOM
