5.3 Search Filters

Pressing the Search button a third time brings up the Search Filters Menu. Use the Search Filters menu
to specify:
The type of operation to be performed: Play from Disk, Play from Archive, Copy from Disk to
Archive, and Copy from Archive to Disk.
The Start and Stop date of the search.
The Start and Stop time of the search.
Searching for recorded activity, events, or alarms.
Searching for a text string.
Which cameras to search inclusively or exclusively.
Operation:
DATE (MM/DD/YY)
Start
01/27/02
Activity
Camera
1
X X
[CANCEL]
[START SEARCH]
Selecting Search Parameters
1. Rotating the Jog to navigate, highlight the box adjacent to the parameters that you wish to modify.
2. Once in the Parameter Box, use the Shuttle to navigate through the fields and the Jog to change
the values.
3. To activate the parameter, use the Shuttle or the Enter button to place an [X] in the check box.
4. When finished, use the Jog to navigate to another parameter.

5.4 Search Results

Activate Search
From the Search Filters menu, use the Jog to navigate to the Start Search parameter. With the Start
Search parameter highlighted, press the Enter button to begin the search operation. When finished
searching, the Search Results window will appear. A maximum of 200 results can be displayed per
search.
Follow the directions on-screen to select, archive, playback, etc.
0150-0193C
Search Filters
Play from Disk
TIME (HH:MM)
Stop Start
01/27/02 20:57
Event Alarm Text
2 3 4 5 6 7 8
X X X X X X X X X X X X X X
Stop
20:59
9 10 11 12 13 14 15 16
X X X X X X X X X X X X X X
65
The following options are
available when an archive
device is connected:
1. Play from Disk.
2. Play from Archive.
3. Copy from Disk to Archive.
4. Copy from Archive to Disk.
X X Hit Camera buttons to
select/deselect individual
cameras. Use the Zoom
button to globally
select/deselect cameras
to search.
