Ethernet Port
The cable connection configuration depends on your
network configuration:
e
For a DVMR Triplex that connects directly to a
Hub or Switch, use a straight through connection.
e
For a DVMR Triplex that connects directly to a
PC, use a cross over connection.
Consult with your MIS personnel for the specific type
of configuration. See section 3.16 for information
about configuring the ethernet settings in the menu
system.
RJ-45 Pin Configuration For Ethernet Port
Pin Use
1 TX+
2 TX-
3 RX+
4 Not Connected
SCSI Port
The unit is equipped with a SCSI port for
connecting external archive devices. The unit only
supports a single SCSI device. The SCSI ID of the
archive device must be set to 0.
The SCSI bus must be terminated, otherwise the
system will not operate properly.
Additional menu setup may be necessary to
configure archive device. See section 3.15.
RS232 Port 1
For a Modem connection or remote control of unit. See section 3.16 for information about configuring
the modem settings in the menu system. See section 8 for RS232 Remote Control Protocols.
DB-9 Pin Configuration For Port 1
Pin Use
1 DCD
2 RX
3 TX
0150-0193C
Pin
5 Not Connected
6
7 Not Connected
8 Not Connected
Pin Use
4 DTR
5 Ground
6 Not Connected
13
Wire Type: Cat 5
Connector Type: RJ-45
Max. Cable Length: 100 meters / 328 ft.
Min. Cable Length: 6 feet / 1.8 meters
Hub Wiring Configuration: Straight Through
PC Wiring Configuration: Cross Over
Use
RX-
Connector: 50 Pin, High Density SCSI-2.
Gender (on unit) : Female
Compatible devices : DVSe, RAID, DAT, AIT,
CD-R, CD-RW
SCSI ID : 0
Pin Use
7 RTS
8 CTS
9 Not Connected
1 2 3 4 5 6 7 8
RJ-45 socket on

back panel.

1
6
DB-9 on back panel.
e
Calibur DVMR Triplex
5
9
