Baud Rate - GE Interlogix TRIPLEX 0150-0193C User Manual

Modem Init String :
1. With the Modem Init String highlighted, press the Enter button to enter the Edit mode. The
character bank will appear in the center of the menu.
2. Press the Sequence button to select the desired character bank.
3. Rotate the Shuttle to navigate the Modem Init String.
4. Rotate the Jog to select a character from the character bank.
5. Use the Number 2 button or rotate the Shuttle to insert the desired character from the character
bank into the Modem Init String and advance to the next character.
6. Use the Number 1 button to insert a blank character.
7. When finished, press the Enter button.
8. To save the changes and reboot, select OK, then press the Enter button. The unit will only reboot
if changes were made to the Modem Init String.
9. To exit the menu without making changes, select Cancel, then press the Enter button. Pressing
the Menu button also exits the menu without making changes.

Baud Rate

Use this menu to configure the baud rate for Port 1. Rotate the
Jog to select a baud rate from the menu.
Save changes and exit the menu: Press the Enter button.
Exit the menu without making changes: Press the Menu button.
Port 2
The RS232 port 2 is used for Event Generation and ASCII Text Insertion. See Section 7 for the RS232
Protocol required to perform these functions.
0150-0193C
POTS Setup
POTS : DISABLE
AT&F1&K3M0E1Q0V1S0=0&R2&C1&D0&H1
[Default Modem String]
@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^
SEQ key selects character bank
'1' key inserts blank character
'2' key inserts selected character
52
[CANCEL] [OK]
Calibur DVMR
1200 Baud
2400 Baud
4800 Baud
9600 Baud
19200 Baud
38400 Baud
57600 Baud
