MULTIQUIP QP-402H Operation And Parts Manual page 63

HONDA GX240K1PMT2/GX240U1PMT2 ENG. — RECOIL STARTER ASSY.
RECOIL STARTER ASSY.
NO. PART NO.
1 28400ZE2W01ZB
1◊ ◊ ◊ ◊ ◊
28400ZE2W01ZB
2 #% 28410ZE2W01ZB
3 #% 28421ZE2W01
4 #% 28422ZE2W01
5 #% 28441ZE2W01
6 #% 28442ZE2W01
7 #% 28443ZE2W01
8 #% 28444ZE2W01
9 # 28469ZE2W01
10 #% 28461ZE2W02
11 # 28462ZE2W01
11 # 28462ZE2W11
11◊ ◊ ◊ ◊ ◊ %
28462ZE2W11
13 #% 90004ZE2W01
14 90008ZE2003
NOTE
QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 63
PART NAME
STARTER ASSY., RECOIL *NH1* BLACK ....... 1............. INCLUDES ITEMS W/#
STARTER ASSY., RECOIL *NH1* BLACK ....... 1............. INCLUDES ITEMS W/%
CASE, RECOIL STARTER *NH1* BLACK
PULLEY, RECOIL STARTER
RACHET, STARTER
SPRING, FRICTION
SPRING, STARTER RETURN
SPRING, RATCHET
RETAINER, SPRING
GRIP. REINFORCEMENT ................................. 1............. S/N 3793540 AND BELOW
GRIP, STARTER
ROPE, RECOIL STARTER ............................... 1............. S/N 3793540 AND BELOW
ROPE, RECOIL STARTER ............................... 1............. S/N 3793541 AND ABOVE
ROPE, RECOIL STARTER
SCREW, CENTER
BOLT, FLANGE 6X10
GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊ ◊ ◊ ◊ ◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
QTY. REMARKS
1
1
2
1
1
2
1
1
1
1
3
