MULTIQUIP QP-402H Operation And Parts Manual page 37

HONDA GX240K1PMT2/GX240U1PMT2 ENG. — CARBURETOR ASSY.
CARBURETOR ASSY.
NO. PART NO.
1 16010ZE2812
2 $%# 16011ZA0931
3 $%# 16013ZA0931
4 $ 16015ZE2005
4 % 16015ZE8005
4◊ ◊ ◊ ◊ ◊ #
16015ZE8005
4A +
5 $%# 16016ZH7W01
6 $%#> 16024ZE1811
6A+
7 $%# 16028ZE0005
7 A +
8 $%# 16044ZE2005
9 16100ZE2W70
9 16100ZE2W71
9◊ ◊ ◊ ◊ ◊
16100ZE2W71
10 $%# 16124ZE0005
11 $%# 16166ZE2W70
12 $%# 16172ZE3W10
13 $%# + 16173001004
14 16211ZE2000
NOTE
QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 37
PART NAME
CARBURETOR, GASKET SET .............. 1 ......... INCLUDES ITEM W/ +
VALVE SET, FLOAT
FLOAT SET
CHAMBER SET, FLOAT ......................... 1 ......... INCLUDES ITEM 4A
................................................................................. INCLUDES ITEM W/>
.......................................................................
CHAMBER SET, FLOAT ......................... 1 ......... INCLUDES ITEM 4A
................................................................................. INCLUDES ITEM W/>
................................................................................. S/N BE70B B AND ABOVE
CHAMBER SET, FLOAT ......................... 1 ......... INCLUDES ITEM 4A
................................................................................. INCLUDES ITEM W/>
GASKET, CHAMBER SET, FLOAT .......... 1 ......... NOT SOLD SEPARATELY
SCREW SET, PILOT
SCREW SET, DRAIN .............................. 1 ......... INCLUDES ITEM 6A
GASKET, SCREW SET, DRAIN ............. 1 ......... NOT SOLD SEPARATELY
SCREW SET .......................................... 1 ......... INCLUDES ITEM 7A
GASKET, SCREW SET .......................... 1 ......... NOT SOLD SEPARATELY
CHOKE SET
CARBURETOR ASSY., BE70B A ........... 1 ......... INCLUDES ITEMS W/$
................................................................................. S/N 3453330 AND BELOW
CARBURETOR ASSY, BE70B B/C ......... 1 ......... INCLUDES ITEMS W/%
................................................................................. S/N 3453331 AND ABOVE
CARBURETOR ASSY, BE70B B ............ 1 ......... INCLUDES ITEMS W/#
SCREW, THROTTLE STOP
NOZZLE, MAIN
COLLAR, SET
GASKET, FUEL STRAINER CUP
INSULATOR, CARBURETOR
GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊ ◊ ◊ ◊ ◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
QTY. REMARKS
1
1
S/N BE70B A AND BELOW
1
1
1
1
1
1
1
