MULTIQUIP QP-402H Operation And Parts Manual page 61

HONDA GX240K1PMT2/GX240U1PMT2 ENG. — PISTON ASSY.
PISTON ASSY.
NO. PART NO.
1 13010ZE2014
1 13010ZE2921
1◊ ◊ ◊ ◊ ◊
13010ZE2921
1 13011ZE2014
1 13011ZE2921
1◊ ◊ ◊ ◊ ◊
13011ZE2921
1 13012ZE2014
1 13012ZE2921
1◊ ◊ ◊ ◊ ◊
13012ZE2921
1 13013ZE2014
1 13013ZE2921
1◊ ◊ ◊ ◊ ◊
13013ZE2921
2 13101ZE2W00
2 13102ZE2W00
2 13103ZE2W00
2 13104ZE2W00
3 13111ZE2000
4 13200ZE2000
4◊ ◊ ◊ ◊ ◊
13200ZE2010
4 13200ZE2305
5 # 90001ZE8000
6 90551ZE1000
NOTE
QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 61
PART NAME
RING SET, PISTON (STD.) ................................ 1 ............ S/N 4081304 AND BELOW
RING SET, PISTON (STD.) ................................ 1 ............ S/N 4081305 AND ABOVE
RING SET, PISTON (STD.)
RING SET, PISTON (0.25) .................................. 1 ............ S/N 4081304 AND BELOW
RING SET, PISTON (0.25) .................................. 1 ............ S/N 4081305 AND ABOVE
RING SET, PISTON (0.25)
RING SET, PISTON (0.50) .................................. 1 ............ S/N 4081304 AND BELOW
RING SET, PISTON (0.50) .................................. 1 ............ S/N 4081305 AND ABOVE
RING SET, PISTON (0.50)
RING SET, PISTON (0.75) .................................. 1 ............. S/N 4081304 AND BELOW
RING SET, PISTON (0.75) .................................. 1 ............. S/N 4081304 AND BELOW
RING SET, PISTON (0.75)
PISTON (STD.)
PISTON (OS 0.25)
PISTON (OS 0.50)
PISTON (0.75)
PIN, PISTON
ROD ASSY., CONNECTING (STANDARD) ......... 1 ............ INCLUDES ITEMS W/#
ROD ASSY., CONNECTING (STANDARD) ......... 1 ............ INCLUDES ITEMS W/#
ROD ASSY., CONNECTING (0.25)
BOLT, CONNECTING ROD
CLIP, PISTON PIN 18 MM
GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊ ◊ ◊ ◊ ◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
QTY. REMARKS
1
1
1
1
1
1
1
1
1
1
2
2
