Camshaft Assembly - MULTIQUIP QP-402H Operation And Parts Manual

HONDA GX240K1PMT2/GX240U1PMT2 ENG. — CAMSHAFT ASSY.
CAMSHAFT ASSY.
NO. PART NO.
1 14100ZE2W00
1 14100ZE2W01
1◊ ◊ ◊ ◊ ◊
14100ZE2W01
2 14410ZE2013
3 14431ZE2010
4 14441ZE2000
5 14451ZE1013
6 # 14568ZE1000
7 14711ZE2000
8 14721ZE2000
9 14751ZE2003
10 14771ZE2000
11 14773ZE2000
12 14781ZE2000
13 14791ZE2010
14 90012ZE0010
15 90206ZE1000
16◊ ◊ ◊ ◊ ◊
14775ZE2010
17 12209ZE8003
17◊ ◊ ◊ ◊ ◊
12209ZE8003
NOTE
QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 35
PART NAME
CAMSHAFT ASSEMBLY ..................................... 1 ......... INCLUDES ITEM W/#
CAMSHAFT ASSEMBLY ..................................... 1 ......... INCLUDES ITEM W/#
CAMSHAFT ASSEMBLY ..................................... 1 ......... INCLUDES ITEM W/#
ROD, PUSH
ARM, VALVE ROCKER
LIFTER, VALVE
PIVOT, ROCKER ARM
SPRING, WEIGHT RETURN
VALVE, INTAKE
VALVE, EXHAUST
SPRING, VALVE
RETAINER, INTAKE VALVE SPRING
RETAINER, EXHAUST VALVE SPRING
ROTATOR, VALVE
PLATE, PUSH ROD GUIDE
BOLT, PIVOT 8MM
NUT, PIVOT ADJ.
SEAT, VALVE SPRING
SEAL, VALVE STEM ........................................... 1 ......... S/N 4081305 AND ABOVE
SEAL, VALVE STEM
GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊ ◊ ◊ ◊ ◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
QTY. REMARKS
2
2
2
2
1
1
1
2
1
1
1
1
2
2
1
1
