MULTIQUIP QP-402H Operation And Parts Manual page 47

HONDA GX240K1PMT2/GX240U1PMT2 ENG. — CYLINDER BARREL ASSY.
CYLINDER BARREL ASSY.
NO. PART NO.
1 15510ZE2043
2 957010601200
3 9405010000
4 91353671004
5 32197ZE2003
6 90013883000
7 90446KE1000
8 9425110000
9 16541ZE2010
10 90013883000
11 34150ZH7003
12 90131883000
13 9410912000
14 12000ZE2815
14 ◊ ◊ ◊ ◊ ◊
12000ZE2406
15 # 91201890003
NOTE
QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 47
PART NAME
SWITCH ASSEMBLY, OIL LEVEL
BOLT, FLANGE 6X12
NUT, FLANGE 10MM
O-RING, 14MM (NOK)
SUB HARNESS ......................................... 1 .......... S/N 3566259 AND BELOW
BOLT, FLANGE 6X12 CT200 ..................... 1 .......... S/N 3566259 AND BELOW
WASHER 8.21X17X0.8
PIN, LOCK 10MM
SHAFT, GOVERNOR ARM
BOLT, FLANGE 6X12 (CT200)
ALERT UNIT, OIL
BOLT, DRAIN PLUG 12X15
WASHER, DRAIN PLUG 12MM
CYLINDER BARREL ASSY., ALERT ........ 1 .......... INCLUDES ITEMS W/#
CYLINDER BARREL ASSY., ALERT ............ 1 ........... INCULDES ITEMS W/#
OIL SEAL 30X46X8
GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊ ◊ ◊ ◊ ◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
QTY. REMARKS
1
2
1
1
1
1
1
1
1
2
2
