Isys™ 2.8" Handheld Wireless Touchpanel
MTX-3 Overall Dimensions (Front and Side Views)
4
5
6
5
8 • Isys™ 2.8" Handheld Wireless Touchpanel: MTX-3
1
2.07 in
(53 mm)
2.55 in
(65 mm)
9
(27 mm)
2
3
2.64 in
(67 mm)
7
8
Operations Guide – DOC. 7066B
Crestron MTX-3
1.04 in
7.94 in
(202 mm)
