Crestron Isys MTX-3 Operation Manual page 10

Isys™ 2.8" Handheld Wireless Touchpanel
6 • Isys™ 2.8" Handheld Wireless Touchpanel: MTX-3
MTX-3 Specifications (Continued)
SPECIFICATION
3
Power Requirements
Power Pack (included)
Default RF ID
Minimum 2-Series Control
4, 5
System Update File
Environmental
Temperature
Humidity
Heat Dissipation
Enclosure
Construction
Dimensions
Height
Width
Depth
Weight
Included Accessories
Power Supply
MTX-3-DS
TPMC-3X-BTP
Available Accessories
CEN-RFGW-EX
1. Any infiNET EX mesh network device that supports expander functionality will effectively extend the
range of the MTX-3 beyond the gateway, provided it is associated with the same gateway as the
MTX-3. Most infiNET EX devices do support extender functionality; exceptions include the
CHV-TSTATEX, HTT-B10EX and the MTX-3.
2. Requires CEN-RFGW-EX or equivalent infiNET EX gateway, which supports up to 100 infiNET EX
network devices inclusive of up to six MTX-3 remotes. Additionally, up to five CLW-EXPEX
infiNET EX Expanders may be added to the network for extended range. All gateways and expanders
sold separately.
3. Power connection made via the included MTX-3-DS Docking Station/Charger. Refer to the latest
revision of the MTX-3-DS Docking Station/Charger guide (Doc. 7077) for additional details. It is
available from the Crestron Web site (www.crestron.com/manuals).
4. The latest software versions can be obtained from the Crestron Web site. Refer to the NOTE
following these footnotes.
5. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
NOTE: Crestron software and any files on the Web site are for authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).
Battery must be recycled. Deliver the battery to an appropriate recycling facility.
Crestron MTX-3
DETAILS
1.2 Amps @ 5 Volts DC;
100-240 Volts AC, 50-60 Hz
09
Version 3.155.1240 or later
32º to 104º F (0º to 40º C)
10% to 90% RH (non-condensing)
20 BTU/Hr
Injection molded plastic, integral docking
station port
1.04 in (27 mm)
2.22 in (57 mm) docked
2.55 in (65 mm)
2.99 in (76 mm) docked
7.94 in (202 mm)
7.84 in (199 mm) docked
7 oz (185 g) including battery
5 Volt Power Pack, 1.2 Amps
Docking Station/Charger
Internal Battery Pack
InfiNET EX Wireless Gateway
Operations Guide – DOC. 7066B
