Conettix ITS-D6682-INTL | Installation Guide | 3.0 Configuring and Programming the D6682
.
Table 2: Netmask Address
Number of Host Bits
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
18. When you are prompted to change the telnet
password, press [N] for No (default setting).
The Setup Mode screen appears again.
Refer to Figure 9 on page 8.
If you use a password, store it in a
secure place. If the password is lost or
forgotten you cannot connect to the
telnet program on this unit again. The
unit must be returned to the factory and
reconditioned before it can receive
another telnet session.
Bosch Security Systems, Inc. | 2/09 | F01U126778-01
Netmask
255.255.255.254
255.255.255.252
255.255.255.248
255.255.255.240
255.255.255.224
255.255.255.192
255.255.255.128
255.255.255.0
255.255.254.0
255.255.252.0
255.255.248.0
255.255.240.0
255.255.224.0
255.255.192.0
255.255.128.0
255.255.0.0
255.254.0.0
255.252.0.0
255.248.0.0
255.240.0.0
255.224.0.0
255.192.0.0
255.128.0.0
255.0.0.0
254.0.0.0
252.0.0.0
248.0.0.0
240.0.0.0
224.0.0.0
192.0.0.0
128.0.0.0
19. Press [1] [ENTER] to configure Channel 1.
Baudrate 9600 appears.
The D6682 must be set to a baud rate
of 38400.
20. Type 38400 and press [ENTER] to change
the baud rate.
I/F Mode (4C) ? appears.
21. Press [ENTER] to accept 4C (default setting)
as the entry.
If a different value appears in parentheses,
type 4C and press [ENTER] to change the
value.
Flow (00) ? appears.
22. Press [ENTER] to accept 00 (default setting)
as the entry.
If a different value appears in parentheses,
type 00 and press [ENTER] to change the
value.
Port No (13257) ? appears.
23. For the Port number, type a number between
2000 and 10000, and press [ENTER].
If using two channels, set different port
numbers for Channel 1 and Channel 2
(shown in the Telnet configuration
screen).
ConnectMode (CC) ? appears.
24. Press [ENTER] to accept CC (default setting)
as the entry, or type CC and press [ENTER]
to change the value.
Datagram Type (00) ? appears.
25. If all field devices are using the same port
number as entered in Step 23, type 00 and
press [ENTER].
To use Datagram Type 02, Bosch
firmware version 6.5.8.0 or later is
required. Refer to the Device Installer
Operation and Installation Guide
(P/N: 4998138688) for more
information.
26. If all field devices are using unique port
numbers, type 02 and press [ENTER].
If Datagram Type 02 is used, enable it
in the D6600 Receiver refer to the
D6600 Program Entry Guide
(P/N: 4998122702).
For more information on Datagram
Types, refer to the Conettix D6600
System Guide (P/N: 4998122712).
9
