RECORDING IMAGES
Screen display items
(7)
NORMAL RECORDING MODE RECORDING
LIVE
ALARM RECORDING MODE
(8)
01-01-04 00: 36: 17
01
(1)
READ INTERVAL :
1
SIZE
SET
SAVE TO PC
:
OFF
(5)
(1) READ INTERVAL (Default setting: 1)
This item allows you to select one of five image display
speeds.
Larger setting numbers correspond to higher speeds;
however, the actual speed will depend on the speed of
your network connection.
* When "(4) AUDIO" is set to "ON", "READ INTERVAL"
cannot be set.
(2) SIZE (Default setting: 1)
This item allows you to select one of six image sizes.
Larger setting numbers correspond to larger image sizes.
(3) QUALITY (Default setting: 2)
This item allows you to select one of three picture quality
settings for PC display. (Only live mode)
1
Lowest quality
2
Standard quality
3
Best quality
(9)
(10)
(11)
STOP
ID:1 ID2:0
ID3:1
:
1
QUALITY :
2
AUDIO :
OFF
CAMERA CONTROL
(2)
(6)
(3)
(4)
(4) AUDIO (Default setting: OFF)
Sound can be played in live mode or play mode.
* Set only for full screen monitoring.
[Settings]
Setting
OFF
Audio will not be played.
ON-5SEC
Audio will be played.
ON-10SEC
Set the audio delay (5, 10, 15, 20, or 30
ON-15SEC
seconds).
ON-20SEC
In Play mode, the speed of fast-forward
ON-30SEC
and frame advance may be affected by
the network environment being used.
Screen indicating the
In addition, if the audio-data reading
reading of audio data
screen appears frequently, the audio
delay (5, 10, 15, 20, or 30 seconds)
should be made longer to match the
network environment.
If this screen continues to appear frequently
even when the delay time is 30 seconds, it
indicates that audio playback is not possible
with the network environment being used.
* Audio delay
The delay time prevents sound dropouts
and the loss of synchrony between video
and sound.
(5) SAVE TO PC (Default setting: OFF)
When this is set to "ON", live images or playback images
can be saved on a PC.
* Size for full screen monitoring.
A user level of ID2 or better is required for the playing
back and saving to PC.
When audio is to be played back, store the audio on the
PC, install "DVR Viewer" for playback ( P. 2), and then
set "AUDIO" to "ON".
Playback will be performed with priority given to audio,
and as a result, images may not be displayed for certain
hardware and software configurations.
Audio playback is not possible for multi-screen display.
(6) [CAMERA CONTROL]
Camera operation panel is displayed on the left side on the
screen and enters Camera control mode.
(7) Image mode
LIVE: Live mode
PLAY: Play mode
(8) Time
Live mode: Displays the current time
Play mode: Displays the recording time
12
